Позиция на иллюстрации
Заводской номер детали
Название детали
4812121947
4812121947
Hydraulic cylinder
1
Guide block
Guide block
2
Piston rod
Piston rod
3
Piston
Piston
4
Guide block
Guide block
5A
4700950417
Seal kit
5
Wiper
Wiper
6
Rod seal
Rod seal
7
Guide Ring
Guide Ring
8
O-ring
O-ring
9
Backup ring
Backup ring
10
O-ring
O-ring
11
O-ring
O-ring
12
O-ring
O-ring
13
Pin
Pin
14
Washer
Washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
