4812116231
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Позиция на иллюстрации
Заводской номер детали
Название детали
4812116231
4812116231
Hydraulic motor, fan
1
Screw
Screw
2
End cover
End cover
3
Seal
Seal
4
Bearing block
Bearing block
5
Drive gear
Drive gear
6
Idler gear
Idler gear
7
Shaft seal
Shaft seal
8
Dowel pin
Dowel pin
9
Gear housing
Gear housing
10
Mounting flange
Mounting flange
11
Shaft seal
Shaft seal
12
Snap ring
Snap ring
13
4700903431
Seal kit
14
4812159763
Sensor w cable
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
