Позиция на иллюстрации
Заводской номер детали
Название детали
1
Rotary group
Rotary group
2
Adjusting piece
Adjusting piece
3
Portplate with valves
Portplate with valves
4
Pump support plate
Pump support plate
5
4/3-Way directional valve
4/3-Way directional valve
10
Housing
Housing
13
Joint pin
Joint pin
14
Cylinder pin
Cylinder pin
20
Locking screw
Locking screw
21
Locking screw
Locking screw
22
Locking screw
Locking screw
23
Locking screw
Locking screw
24
Locking screw
Locking screw
25
Locking screw
Locking screw
27
Double break-off plug
Double break-off plug
28
4812158198
Orifice
31
Clamping pin
Clamping pin
41
4812157789
O-ring
49
4700936313
Orifice
98
4700940674
Seal kit, cpl
