Каталог запасных частей к технике: DYNAPAC CA1400. Propulsion system back
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
31
32
33
34
35
36
37
38
39
40
41
42
43
44
46
47
47
48
49
50
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812118623 | Hydraulic motor | |
| 2 | 4812124562 | Hydraulic hose | |
| 3 | 4812124561 | Hydraulic hose | |
| 4 | 4700902286 | Lock nut | |
| 5 | 4700791805 | Stud | |
| 6 | 4812117061 | Clamp | |
| 7 | 4812113941 | Hose holder clip | |
| 8 | 4700287295 | Clamp | |
| 9 | 4700287294 | Cover plate | |
| 10 | 4812117075 | Hydraulic hose | |
| 11 | 4700791414 | T-connection, O-ring with swivel | |
| 12 | 4700792673 | Straight connector orfs | |
| 13 | 4812124829 | Hydraulic hose | |
| 14 | 4700792743 | Elbow connector | |
| 15 | 4812116156 | Hydraulic oil tank | |
| 16 | 4812124536 | Hydraulic hose | |
| 17 | 4812123627 | Hydraulic pump | |
| 18 | 4812124561 | Hydraulic hose | |
| 19 | 4700903768 | Threaded stud | |
| 20 | 4700902286 | Lock nut | |
| 21 | 4700792743 | Elbow connector | |
| 22 | 4812117272 | Hydraulic hose | |
| 23 | 4700415329 | Hydraulic hand pump | |
| 24 | 4812124779 | Hydraulic hose | |
| 25 | 4700792252 | Pipe clamp | |
| 26 | 4700791932 | Plate | |
| 27 | 4700791860 | Stud | |
| 28 | 4700902286 | Lock nut | |
| 29 | 4700500019 | Hex. screw | |
| 31 | 4812124779 | Hydraulic hose | |
| 32 | 4812124798 | Hoose clamp | |
| 33 | 4812124799 | Hoose clamp | |
| 34 | 4812124585 | Hydraulic hose | |
| 35 | 4812124543 | Bulkhead union ORFS | |
| 36 | 4812124543 | Bulkhead union ORFS | |
| 37 | 4812124800 | Hoose clamp | |
| 38 | 4812124800 | Hoose clamp | |
| 39 | 4700904557 | Washer | |
| 40 | 4700500048 | Hex. screw | |
| 41 | 4700791830 | Adapter | |
| 42 | 4812113941 | Hose holder clip | |
| 43 | 4700396657 | Hose clamp | |
| 44 | 4700791712 | Cover plate | |
| 46 | 4700791711 | Pipe clamp | |
| 47 | 5501178300 | Connector elbow | |
| 48 | 4700792157 | Elbow adapter 45 | |
| 49 | 4700904781 | Adapter | |
| 50 | 4700791632 | Straight connector orfs | |
| 51 | 4700392552 | Hydraulic block | |
| 52 | 4700791409 | Straight connector orfs | |
| 53 | 4700791823 | Adapter |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
