Каталог запасных частей к технике: DYNAPAC CA1400. Electrical cables
1
1
2
3
4
4
5
5
6
7
8
8
9
10
11
12
12
13
13
14
14
14
14
15
16
17
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812118899 | Cable harness | |
| 2 | 4700901227 | Fuse | |
| 3 | 4700901228 | Fuse | |
| 4 | 4812123871 | Wiring harness | |
| 5 | 4812123924 | Wiring harness | |
| 6 | 4812121121 | Battery cable | |
| 7 | 4700903956 | Relay | |
| 8 | 4812119793 | Connection cable coarse | |
| 9 | 4812119795 | Connection cable coarse | |
| 10 | 4812119794 | Battery cable | |
| 11 | 4700343550 | Connection cable | |
| 12 | 4812123870 | Wiring harness | |
| 13 | 4700313041 | Cable tie | |
| 14 | 4700792441 | Cable tie with holder | |
| 15 | 4700904294 | Fuse | |
| 16 | 4700586001 | Lock nut | |
| 17 | 4700904281 | Washer | |
| 18 | 4700500060 | Screw | |
| 19 | 4700904042 | Fuse | |
| 20 | 4700904229 | Washer | |
| 21 | 4700508019 | Cylinder screw | |
| 22 | 4700904038 | Fuse | |
| 23 | 4700904039 | Fuse | |
| 24 | 4700570005 | Hex. nut | |
| 25 | 4700904229 | Washer | |
| 26 | 0248998073 | Threaded stud | |
| 27 | Batteryholder | Battery holder | |
| 28 | Baterydisconnector | Batery disconnector | |
| 29 | Alarmmodule | Back-up alarm module | |
| 30 | Relayholder | Relay holder | |
| 31 | ECUmodule | Standard ECU module | |
| 32 | Holder(Fusebox,Buzzer,Ignition) | Holder, Fuse box, Buzzer, Ignition |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
