Каталог запасных частей к технике: Doosan SOLAR 420LC-V. COVER (4)
621-01744
110508-00131
6A
6A
6B
6B
6B
6B
6B
6BA
6BA
6BA
6BA
6C
6D
6E
6F
6G
6H
6I
6J
6J
6J
6K
6K
6L
6M
6N
6O
6P
6Q
6R
6S
10
10
10
10
10
10
10
10
10
12
13
20
24
24
25
25
25
25
26
26
26
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 621-01744 | 621-01744 | COVER ASS`Y | |
| 110508-00131 | 110508-00131 | COVER ASSY | |
| 6 | 621-01691B | BATTERY COVER ASSY | |
| 6 | 621-01691C | BATTERY COVER ASSY | |
| 6 | 621-01691E | BATTERY COVER ASSY | |
| 6 | 621-01691G | BATTERY COVER ASSY | |
| 6 | 621-01691H | BATTERY COVER ASSY | |
| 6A | 621-01692B | COVER, BATTERY | |
| 6A | 621-01692C | COVER, BATTERY | |
| 6B | 621-02001 | COVER | |
| 6B | 621-02001A | COVER | |
| 6B | 621-02001B | COVER | |
| 6B | 621-02001C | COVER | |
| 6B | 621-02001E | COVER | |
| 6BA | 125-00034 | LOCK | |
| 6BA | 125-00082 | LOCK | |
| 6BA | 125-00082A | LOCK | |
| 6BA | K1006422 | LOCK | |
| 6C | 2145-1243 | STAY | |
| 6D | S0512053 | BOLT M10X1.5X25 | |
| 6E | S5010613 | WASHER;PLAIN | |
| 6F | 2621-3003B | PLATE | |
| 6G | 2114-1727B | Shim | |
| 6H | S0555753 | BOLT M8X1.25X25 | |
| 6I | S5010513 | WASHER;PLAIN M8 | |
| 6J | 2114-1058D29 | WASHER | |
| 6K | 2705-9002 | PIN;LOCK | |
| 6L | BUSHING,RUBBER | BUSHING,RUBBER | |
| 6M | BUSHING,RUBBER | BUSHING,RUBBER | |
| 6N | BUSHING,RUBBER | BUSHING,RUBBER | |
| 6O | BUSHING,RUBBER | BUSHING,RUBBER | |
| 6P | 621-01694A | COVER | |
| 6Q | S0509253 | Bolt | |
| 6R | S5102503 | WASHER;SPRING | |
| 6S | S5010513 | WASHER;PLAIN M8 | |
| 10 | 145-00045B | STAY | |
| 10 | 145-00045C | STAY | |
| 10 | 101582-00226 | STAY | |
| 12 | 2120-2196D9 | BOLT;SET M12X1.75X25 | |
| 13 | 2120-2196D11 | BOLT;SET | |
| 20 | S5010713 | WASHER;PLAIN | |
| 24 | S5102703 | WASHER;SPRING M10 | |
| 25 | 903-00052 | MIRROR;MAIN | |
| 25 | 2903-9012A | MIRROR;MAIN | |
| 25 | 903-00068 | MIRROR;MAIN | |
| 25 | K1040606 | MIRROR, SIDE | |
| 26 | 145-00052 | STAY | |
| 26 | 101582-00227 | STAY | |
| 27 | 124-00246 | CLAMP | |
| 28 | S0561153 | Bolt | |
| 29 | 2114-1154 | WASHER | |
| 30 | 124-00216 | CLAMP | |
| 31 | 124-00217 | CLAMP | |
| 32 | S0561253 | BOLT M12X1.75X75 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
