Каталог запасных частей к технике: Doosan SOLAR 420LC-V. COVER (3)
621-01744
110508-00131
5A
5A
5A
5A
5A
5A
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5B
5BA
5BA
5BA
5BA
5D
5E
5F
5G
5H
5I
5J
5K
5L
5M
5N
5O
5O
5O
5O
5P
5P
5P
5P
5Q
5R
5R
5R
5R
5S
5S
5S
5S
5T
5T
5T
5T
5U
5U
5U
5U
12
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 621-01744 | 621-01744 | COVER ASS`Y | |
| 110508-00131 | 110508-00131 | COVER ASSY | |
| 5 | 621-01648C | SIDE DOOR ASSY | |
| 5 | 621-02198 | SIDE DOOR ASSY | |
| 5 | 621-01648C | SIDE DOOR ASSY | |
| 5 | 621-01648E | SIDE DOOR ASSY | |
| 5 | 621-01648G | SIDE DOOR ASSY | |
| 5 | 621-01648H | SIDE DOOR ASSY | |
| 5 | 621-01648I | SIDE DOOR ASSY | |
| 5 | 110982-00282 | DOOR ASSY,SIDE | |
| 5 | 110982-00271 | DOOR ASSY,SIDE, PUMP | |
| 5A | 195-01564A | SUPPORT | |
| 5A | 195-01564B | SUPPORT | |
| 5A | 110958-00356 | SUPPORT, SIDE DOOR | |
| 5B | 621-01647B | DOOR, SIDE | |
| 5B | 621-02199 | DOOR, SIDE | |
| 5B | 621-01647B | DOOR, SIDE | |
| 5B | 621-01647C | DOOR, SIDE | |
| 5B | 621-01647E | DOOR, SIDE | |
| 5B | 621-01647G | DOOR, SIDE | |
| 5B | 110982-00283 | DOOR,SIDE | |
| 5B | 110982-00272 | DOOR,SIDE, PUMP ROOM | |
| 5BA | 125-00035 | LOCK(R.H.) | |
| 5BA | 125-00083 | LOCK(R.H.) | |
| 5BA | 125-00083A | LOCK(R.H.) | |
| 5BA | K1006423 | LOCK(R.H.) | |
| 5D | 2145-1237 | STAY | |
| 5E | S4012733 | NUT M12 | |
| 5F | 2114-1058D30 | WASHER;PLAIN | |
| 5G | S0508753 | BOLT M8X1.25X18 | |
| 5H | S5010513 | WASHER;PLAIN M8 | |
| 5I | 2891-1912 | SEAT, SCREW | |
| 5J | 161-00320 | PLATE, STOPPER | |
| 5K | S0512053 | BOLT M10X1.5X25 | |
| 5L | S4012633 | NUT M10X1.5 | |
| 5M | 2114-1058D10 | WASHER | |
| 5N | 2161-2226 | STOPPER | |
| 5O | 2161-9052 | STOPPER;PLATE | |
| 5O | 250201-00028 | PLATE | |
| 5P | 2161-9053 | STOPPER;RUBBER | |
| 5P | 110956-00002 | STOPPER, RUBBER | |
| 5Q | S4012633 | NUT M10X1.5 | |
| 5R | 2116-1522 | PLATE | |
| 5R | 110947-00027 | SHIM | |
| 5S | S5010313 | WASHER;PLAIN | |
| 5T | S0504553 | BOLT M6X1.0X14 | |
| 5T | S0504653 | BOLT M6X1.0X12 | |
| 5U | S0504453 | BOLT M6X1.0X12 | |
| 5U | S0504353 | BOLT M6X1.0X10 | |
| 12 | 2120-2196D9 | BOLT;SET M12X1.75X25 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
