Каталог запасных частей к технике: Doosan SOLAR 210W-V. CABIN (1)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
60
78
78
78
78
78
78
73
72
71
70
70
70
69
69
69
68
65
65
65
64
79
59
58
57
56
51
51
48
47
47
46
45
44
105
105
121
120
119
118
118
117
117
116
114
108
107
106
43
104
103
99
98
98
96
94
92
85
81
81
80
2-1
2-12
2-11
2-10
2-9
2-8
2-7
2-6
2-5
2-3
2-2
2-1
2-13
2-13
2
2
1
220101-00693G
220101-00693B
220101-00693A
220101-00693
622-00210H
622-00210E
622-00210C
622-00210B
4
42
42
38
37
36
35
33
31
31
31
31
31
30
30
30
30
30
29
29
29
15
622-00210A
3
3
3
3
2-22
2-21
2-20
2-19
2-18
2-17
2-16
2-15
2-15
2-14
2-14
Позиция на иллюстрации Заводской номер детали Название детали
60 S4010003 NUT M3X0.5
78 430218-00150 Nozzle assy
78 K1002429 NOZZLE ASS'Y
78 2114-1855 WASHER ASS'Y
73 2161-2209 STOPPER;RUBBER LH
72 2161-2210 STOPPER;RUBBER RH
71 2161-2207 STOPPER;RUBBER LH
70 2114-1058D52 WASHER
69 2140-1338 PIPE;SPACER
68 2161-2208 STOPPER;RUBBER RH
65 S3450993 SCREW M6X1.0X25
64 2161-2211 STOPPER;RUBBER
79 S3643359 SCREW;TAPPING
59 S5020013 WASHER;PLAIN M3
58 S3450343 SCREW M3X0.5X10
57 2891-1323 PLATE
56 530-00212 HARNESS;CABIN LAMP
51 S3450953 SCREW M6X1.0X12
48 507-00005 BLADE;WIPER
47 300704-00012 Arm, wiper
47 2541-6020 WIPER ARM ASS'Y
46 S5102203 WASHER SPRING M5
45 S5010213 WASHER PLAIN M5
44 S3450833 SCREW M5X0.8X12
105 160-00038 RUBBER
121 2120-2166D25 Bolt
120 2903-6006 Mirror, room
119 2197-1712 Bracket
118 162-00031 TRIM;RUBBER
117 2161-2289A RUBBER;CUSHION
117 2161-2289 RUBBER;CUSHION
116 195-02099 BRACKET
114 2514-1013 HOLDER
108 530-00251 HARNESS;W/MOTOR JOINT
107 S3453118 SCREW M8X1.25X20
106 142-00067 STRIKER
43 538-00009 MOTOR;WIPER
104 162-00027 STRIP;WEATHER L=920
103 2160-1026 TRIM
99 2114-1058D45 WASHER M10
98 2114-1898D2 WASHER M8
96 2160-1310 BUSHING;RUBBER
94 110-00230 BUSHING;RUBBER
92 621-01991 COVER;WIPER MOTOR
85 2161-2212 STOPPER;RUBBER
81 120-00226 BOLT;KNOB M8X1.25X30
80 195-01549A BRACKET
2-1 622-00171A Door, front
2-12 125-00043 CATCH
2-11 2110-1347 BUSH 135L
2-10 S4032633 NUT M10X1.25
2-9 2161-2069 STOPPER
2-8 161-00395 DAMPER
2-7 161-00395 DAMPER
2-6 161-00395 DAMPER
2-5 125-00031A CATCH
2-3 161-00395 DAMPER
2-2 903-00055A GLASS 6.76T
2-1 622-00171B Door, front
2-13 2120-2166D36 BOLT M6X1.0X20
2 622-00170A Door assy, front
2 622-00170 Door assy, front
1 CAB Cab assy
220101-00693G 220101-00693G Cabin assy
220101-00693B 220101-00693B Cabin assy
220101-00693A 220101-00693A Cabin assy
220101-00693 220101-00693 Cabin assy
622-00210H 622-00210H Cabin assy
622-00210E 622-00210E Cabin assy
622-00210C 622-00210C Cabin assy
622-00210B 622-00210B Cabin assy
4 903-00049 GLASS;FRONT LOWER
42 198-00036A STRIP;WEATHER
42 162-00030 STRIP;WEATHER
38 621-01990 COVER;AUTO LOCK
37 2125-9056 CATCH;AUTO LOCK
36 2120-2166D4 BOLT M10X1.5X20
35 2197-1711 BRACKET;AUTO LOCK
33 2120-2166D5 BOLT M8X1.25X20
31 S5102303 WASHER;SPRING M6
30 S5010313 WASHER;PLAIN
29 S3450973 SCREW M6X1.0X16
15 162-00025A STRIP;WEATHER 3800L
622-00210A 622-00210A Cabin assy
3 2154-1033 ROLLER
2-22 K1000868 RUBBER 920L
2-21 S5102503 WASHER;SPRING
2-20 2114-1898D2 WASHER M8
2-19 S4012533 NUT M8X1.25
2-18 2160-1307 CAP;RUBBER
2-17 129-00146A SPRING
2-16 133-00168 BAR
2-15 2114-1898D3 WASHER
2-14 2114-2031D3 WASHER;SPRING M6
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
