Каталог запасных частей к технике: Doosan SOLAR 170W-V. AXLE CASING-REAR AXLE
10
30
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
90
100
120
130
140
150
180
190
240
250
260
260
290
290
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4472 319 041 | Case, axle | |
| 30 | 4472 319 049 | Case, axle | |
| 50 | 0730 006 521 | Shim | |
| 50 | 0730 006 524 | Shim | |
| 50 | 0730 002 277 | Shim | |
| 50 | 0730 006 522 | Shim | |
| 50 | 0730 006 523 | Shim | |
| 50 | 0730 001 010 | Shim | |
| 50 | 0730 006 525 | Shim | |
| 50 | 0730 006 526 | Shim | |
| 50 | 0730 006 527 | Shim | |
| 50 | 0730 006 528 | Shim | |
| 50 | 0730 006 529 | Shim | |
| 50 | 0730 001 009 | Shim | |
| 50 | 0730 008 836 | Shim | |
| 50 | 0730 008 837 | Shim | |
| 50 | 0730 005 816 | Shim | |
| 50 | 0730 008 051 | Shim | |
| 50 | 0730 008 052 | Shim | |
| 50 | 0730 005 817 | Shim | |
| 50 | 0730 008 053 | Shim | |
| 50 | 0730 008 154 | SHIM | |
| 50 | 0730 006 519 | Shim | |
| 50 | 0730 000 127 | Shim | |
| 50 | 0730 006 510 | Shim | |
| 50 | 0730 000 126 | Shim | |
| 50 | 0730 006 511 | Shim | |
| 50 | 0730 002 280 | Shim | |
| 50 | 0730 006 512 | Shim | |
| 50 | 0730 001 012 | Shim | |
| 50 | 0730 005 708 | Shim | |
| 50 | 0730 000 125 | Shim | |
| 50 | 0730 005 709 | Shim | |
| 50 | 0730 006 513 | Shim | |
| 50 | 0730 006 514 | Shim | |
| 50 | 0730 006 515 | Shim | |
| 50 | 0730 000 124 | Shim | |
| 50 | 0730 006 516 | Shim | |
| 50 | 0730 006 517 | Shim | |
| 50 | 0730 006 518 | Shim | |
| 50 | 0730 000 123 | Shim | |
| 50 | 0730 006 520 | Shim | |
| 50 | 0730 001 011 | Shim | |
| 90 | 0750 117 380 | Bearing, roller | |
| 100 | 0750 117 024 | Bearing, roller | |
| 120 | 0634 304 012 | O-ring | |
| 130 | 0636 016 151 | Screw, hex. | |
| 140 | 0730 101 840 | Washer | |
| 150 | 0736 008 053 | Bolt, fitting | |
| 180 | 0730 365 124 | Plate, type.introduction date | |
| 190 | 0631 311 009 | Stud, grooved | |
| 240 | 0636 302 018 | Plug, screw | |
| 250 | 0750 108 029 | Plug, screw | |
| 260 | 0634 303 485 | O-ring | |
| 290 | 4472 319 063 | Shaft, stub |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
