400-01826
400-01826
1
1
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
4
4
5
5
Позиция на иллюстрации
Заводской номер детали
Название детали
400-01826
400-01826
Rear outrigger piping
1
2184-1196D159
Hose
1
DS2011407
Hose
2
2181-4133D39
Adapter
3
S8000181
O-RING
4
S8030061
O-RING
5
2160-1201D19
Bushing,rubber
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
