918-00049
1
2
3
4
4A
4A
4B
4C
4D
4D
4E
4E
4E
5
5
6
6
Позиция на иллюстрации
Заводской номер детали
Название детали
918-00049
918-00049
Option assy-german
1
624-00007A
Weight, counter
2
2145-1301B
Stay
3
2145-1304
Stay
4
2401-1292
Travel motor assy
4A
2401-9300
Motor, travel
4B
2181-2823D11
Plug
4C
S8000291
O-RING
4D
2181-1890D2
PLUG PT1/4
4E
S8000111
O-RING
5
2197-2482
Bracket, reflector
6
S3051201
Bolt, wing
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
