1
2
3
4
5
6
6
6
7
8
9
10
11
12
13
14
15
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
65.06404-5032
Housing assy
1
65.06404-5003B
HOUSING ASS'Y
2
65.06904A0004
GASKET
3
06.01493-4217
BOLT M10X1.25X90
4
06.01493-4216
BOLT M10X1.25X85
5
06.01943-3217
BOLT M10X1.25X30
6
06.16044-0211
Washer
7
65.06402-5015
ELEMENT;THERMOSTAT
8
65.06904-0003
PACKING
9
65.06405-0012
OUTLET;WATER
9
65.06405-0039
Outlet, water
9
65.06405-0012A
OUTLET;WATER
10
65.90201-0037
BOLT;SPACER
11
06.01923-3114
Bolt
12
06.15010-2311
Washer
13
06.16731-2107
Washer
14
65.96301-0045C
HOSE;RUBBER
15
06.67020-0106
Clamp
16
65.90320-0019
PLUG;SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
