Каталог запасных частей к технике: Doosan SOLAR 130W-V(1). OIL TANK
25
17
18
19
19
19
19
19
20
20A
20A
20B
20B
20C
20C
21
21
21
21
21
21-1
22
23
23
24
26
27
28
29
30
31
31
31
31
31
32
33
34
35
36
37
37
37
37
38
10
10
10
10
10
10
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
3
4
5
6
7
8
9
2470-2070A
10
10
10
10
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
13
14
15
15
15
15
15
16
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 25 | 2427-1001 | Seat, valve | |
| 16 | 2140-1570A | Pipe, suction | |
| 17 | 2474-9016A | FILTER;SUCTION | |
| 18 | 2181-1950D7 | PLUG PF1/2 | |
| 19 | S8000181 | O-RING | |
| 19 | S8000181 | O-RING | |
| 20 | 2119-1007 | GAUGE;LEVEL | |
| 20A | 2412-1008 | Plate | |
| 20B | S8000110 | O-ring | |
| 20C | 2120-1063 | Bolt | |
| 21 | 2422-9027 | Breather, air | |
| 21 | 422-00027 | Breather, air | |
| 21-1 | 180-00200 | PACKING | |
| 22 | S8011200 | O-RING | |
| 23 | 2181-1116D2 | PLUG | |
| 24 | 2114-1816 | WASHER;HARD | |
| 16 | 2140-1570 | Pipe, suction | |
| 26 | S5103001 | Washer, spring | |
| 27 | S4033033 | Nut | |
| 28 | 2181-1019B | Cover | |
| 29 | 2474-1001 | Element, drain | |
| 30 | 2426-1001 | Valve | |
| 31 | 2549-1135D2 | SWITCH;PRESSURE | |
| 31 | 2181-2667 | PLUG | |
| 32 | S8180221 | PACKING | |
| 33 | S0515053 | BOLT M12X1.75X25 | |
| 34 | S5102703 | WASHER;SPRING M10 | |
| 35 | S4012733 | NUT M12 | |
| 36 | 2180-9187 | Gasket | |
| 37 | S2202961 | Bolt, socket | |
| 37 | S2202761 | Bolt, socket | |
| 38 | 2627-1262 | Cover | |
| 10 | S0512053 | BOLT M10X1.5X25 | |
| 1 | 2470-2069C | Tank, oil | |
| 1 | 2470-2069E | Tank, oil | |
| 1 | 2470-2069H | Tank, oil | |
| 1 | 2470-2132 | Tank, oil | |
| 1 | 2470-2132A | Tank, oil | |
| 1 | 2470-2132B | Tank, oil | |
| 1 | 2470-2132C | Tank, oil | |
| 2 | S0521351 | Bolt | |
| 3 | 2114-1813 | SHIM D20X0.8T | |
| 4 | 2114-1814 | SHIM D20X1.6T | |
| 5 | 2473-1076 | COVER | |
| 6 | S8011450 | O-RING | |
| 7 | 2129-1222 | SPRING | |
| 8 | 2426-9009 | VALVE;BY-PASS | |
| 9 | 2474-9003B | ELEMENT;FILTER(OIL TANK) | |
| 2470-2070A | 2470-2070A | Oil tank assy | |
| 10 | S0512053 | BOLT M10X1.5X25 | |
| 10 | S0512053 | BOLT M10X1.5X25 | |
| 11 | S5102603 | WASHER;SPRING M10 | |
| 11 | S5102603 | WASHER;SPRING M10 | |
| 11 | S5102603 | WASHER;SPRING M10 | |
| 12 | 2473-1081A | Cover | |
| 12 | 2473-1088A | Cover | |
| 12 | 2473-1088B | COVER | |
| 13 | S8011650 | O-RING | |
| 14 | 2136-1428 | ROD | |
| 14 | 2136-1434 | ROD | |
| 15 | 2129-1008 | SPRING | |
| 15 | 2129-1008 | SPRING | |
| 16 | 2140-1220B | Pipe, suction |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
