Каталог запасных частей к технике: Doosan SOLAR 130W-V(1). FRONT PIPING
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
3
4
5
6
7
8
10
10
10
10
11
12
13
13
14
14
14
14
14
14
14
15
15
15
15
15
15
15
15
15
15
15
15
15
15
17
17
17
17
17
17
17
17
17
17
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
20
21
21
21
22
22
22
22
22
22
22
22
22
23
23
23
24
24
24
24
24
24
24
24
25
25
26
26
27
27
28
29
30
31
31
31
31
31
31
31
31
31
31
31
31
31
31
31
31
31
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
32
33
33
34
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2400-1791A | 2400-1791A | Front piping | |
| 1 | 2440-9230 | Cylinder, boom | |
| 1 | 2440-9309B | Cylinder, boom | |
| 1 | 2440-9309 | Boom cylinder | |
| 1 | 2440-9309A | Boom cylinder | |
| 2 | 2440-9231 | Cylinder, boom | |
| 2 | 2440-9310 | Boom cylinder | |
| 2 | 2440-9310A | Boom cylinder | |
| 2 | 2440-9310B | Cylinder, boom | |
| 3 | 2440-9242 | Arm cylinder | |
| 3 | 2440-9242A | CYLINDER;ARM | |
| 4 | 2440-9233B | Cylinder, bucket | |
| 4 | 2440-9233A | Cylinder, bucket | |
| 4 | 2440-9233 | Cylinder, bucket | |
| 5 | 2140-1265B | Pipe | |
| 6 | 2140-1266B | Pipe | |
| 7 | 2140-1267B | Pipe | |
| 8 | 2140-1268B | Pipe | |
| 10 | 2140-1269A | Pipe | |
| 10 | 2140-1269B | PIPE;BUCKET | |
| 11 | 2184-1200D29 | Hose | |
| 12 | 2184-1196D63 | Hose | |
| 13 | 2184-1196D5 | HOSE 3/4-1450L | |
| 14 | 2197-2092 | BRACKET | |
| 14 | 2197-1519 | Bracket | |
| 14 | 2197-1519A | Bracket | |
| 15 | 2124-1599 | CLAMP | |
| 15 | 2124-1599 | CLAMP | |
| 15 | 2124-1599 | CLAMP | |
| 17 | 2124-1601A | Clamp, pipe | |
| 17 | 124-00171 | CLAMP | |
| 18 | 2161-2250 | Rubber | |
| 18 | 2161-2250A | RUBBER | |
| 20 | 2181-9079 | FLANGE | |
| 21 | 2181-2627D1 | ADAPTER | |
| 22 | S8030121 | O-RING | |
| 23 | S8000231 | O-RING | |
| 24 | 2181-4133D3 | ADAPTER | |
| 25 | S8030081 | O-RING | |
| 26 | S8000181 | O-RING | |
| 27 | 2180-1026D2 | O-RING | |
| 28 | S2212361 | Bolt, socket | |
| 29 | S2212261 | Socket-head bolt | |
| 30 | S0561353 | BOLT M12X1.75X80 | |
| 31 | S0560853 | BOLT M12X1.75X55 | |
| 31 | S0560853 | BOLT M12X1.75X55 | |
| 32 | S5102703 | WASHER;SPRING M10 | |
| 32 | S5102703 | WASHER;SPRING M10 | |
| 33 | S0515253 | BOLT M12X1.75X30 | |
| 34 | 124-00166 | CLAMP;PIPE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
