1
2
2
3
4
4
5
5
6
6
7
7
8
8
Позиция на иллюстрации
Заводской номер детали
Название детали
2270-9404В
2270-9404В
LOWER ROLLER ASSY
1
2270-6083А
ROLLER
2
2271-6020А
COLLER
3
2112-6013
SHAFT
4
2110-6070
BUSHING
5
2123-6085
PIN
6
2180-6080А
SEAL, GROUP
7
2180-6081
O-RING
8
PLUG
Plug
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
