Каталог запасных частей к технике: Doosan S500LC-V. BUCKET CYLINDER
440-0001ЗАКТ
440-0001ЗАКТ
1
1
2
2
2
3
3
3
4
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 440-00016В | 440-00016В | CYLINDER, BUCKET | |
| 440-0001ЗАКТ | 440-0001ЗАКТ | SEAL KIT | |
| 440-00016Е | 440-00016Е | CYLINDER, BUCKET | |
| 440-00016С | 440-00016С | CYLINDER, BUCKET | |
| 440-00016А | 440-00016А | CYLINDER, BUCKET | |
| 1 | 53U515-0 | TUBE ASSY | |
| 1 | 53U515-1 | TUBE ASSY | |
| 2 | 00В102-1 | BUSH | |
| 2 | 03В685-2 | BUSH | |
| 2 | 00В102-0 | BUSH | |
| 3 | 53U516-0 | ROD ASSY | |
| 3 | 53U516-6 | ROD ASSY | |
| 3 | 53U516-4 | ROD ASSY | |
| 4 | 00В102-0 | BUSH | |
| 4 | 03В685-2 | BUSH | |
| 4 | 00В102-1 | BUSH | |
| 5 | 53U541-0 | COVER, ROD | |
| 5 | 53U541-1 | COVER, ROD | |
| 6 | Е8412227 | BUSH, DU | |
| 7 | 00М574-0 | RING, RETAINING | |
| 8 | Е5500350 | SEAL, BUFFER | |
| 9 | Е5303590 | PACKING, U | |
| 10 | Е6020350 | WIPER, DUST | |
| 11 | 00М799-0 | RING, RETAINING | |
| 12 | Е6311841 | O-RING | |
| 13 | 04В438-0 | RING, BACK-UP | |
| 14 | Е6490091 | O-RING | |
| 15 | 00С316-0 | RING, CUSHION | |
| 16 | 53А518-0 | PISTON | |
| 17 | Е5130380 | SEAL, SLIPPER | |
| 18 | 00Z113-0 | RING, WEAR | |
| 19 | 00R105-0 | RING, SLYD | |
| 20 | Е6311481 | O-RING | |
| 21 | 53А429-0 | RING, BACK-UP | |
| 22 | 53U423-0 | NUT, PISTON | |
| 22 | 55А371-0 | NUT, PISTON | |
| 23 | Е1330544 | SCREW, SET | |
| 24 | Е0502709 | BOLT, SOCKET | |
| 25 | 53U517-0 | PIPE BAND ASSY -R | |
| 26 | 00Р381-1 | BAND, PIPE | |
| 27 | Е3110112 | WASHER, SPRING | |
| 28 | Е0020963 | BOLT, HEX. | |
| 29 | 53U520-0 | PIPE BAND ASSY -H | |
| 30 | 00Р381-1 | BAND, PIPE | |
| 31 | Е3110112 | WASHER, SPRING | |
| 32 | Е0020963 | BOLT, HEX. | |
| 33 | 53U518-0 | PIPE ASSY -H | |
| 34 | Е6300881 | O-RING | |
| 35 | Е3110122 | WASHER, SPRING | |
| 36 | Е0501846 | BOLT, SOCKET | |
| 37 | Е0020973 | BOLT, HEX. | |
| 38 | Е3110112 | WASHER, SPRING | |
| 39 | Е2022043 | NUT, HEX. | |
| 40 | 53U519-0 | PIPE ASSY -R | |
| 41 | Е6300881 | O-RING | |
| 42 | Е3110122 | WASHER, SPRING | |
| 43 | Е0501846 | BOLT, SOCKET | |
| 44 | 00U211-0 | U-BOLT | |
| 45 | Е3110112 | WASHER, SPRING | |
| 46 | Е2021042 | NUT, HEX. | |
| 47 | Е8841022 | NIPPLE, GREASE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
