1
2
2
3
3
4
5
6
7
8
9
9
10
10
10
10
10
10
10
10
10
10
10
Позиция на иллюстрации
Заводской номер детали
Название детали
195-01654
195-01654
SUPPORT ASSY
1
195-01657A
SUPPORT
2
195-01659B
SUPPORT
2
195-01659C
SUPPORT
3
195-01580C
SUPPORT
3
195-02103
SUPPORT
4
195-01461B
Support
5
195-01878
SUPPORT
6
195-01457B
Support
7
621-01690A
COVER
8
621-01587B
Cover
9
2120-2196D6
Bolt
10
2120-2196D9
BOLT;SET M12X1.75X25
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
