7
7А
7А
7В
7С
7D
7D
7Е
7Е
7F
7F
7G
7G
7Н
7Н
7Н
25
S057O666
Позиция на иллюстрации
Заводской номер детали
Название детали
604-00129
604-00129
TRACK ASSY
7
2270-9025
LOWER ROLLER ASSY
7А
2270-6115А
BODY ASSY
7В
2271-6021А
COLLAR
7С
2112-6005
SHAFT
7D
S8010700
O-RING
7Е
2180-6096
SEAL, FLOATING
7F
2123-6118
PIN
7G
2181-1116D2
PLUG
7Н
2110-6083А
BUSHING
25
S057O661
BOLT M20X2.5X90
S057O666
S057O666
BOLT M20X2.5X90
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
