Каталог запасных частей к технике: Doosan S340LC-V. CYLINDER BLOCK
2
2
2
2
2
3
4
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
7
7
7
7
8
8
9
9
10
11
11
12
12
12
12
12-1
13
14
15
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 001 -1 | 65.01101-6213A | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213B | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213C | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213D | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213E | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213F | CYLINDER BLOCK ASSY | |
| 001 -1 | 65.01101-6213G | CYLINDER BLOCK ASSY | |
| 2 | 65.01101-0212 | BLOCK, CYLINDER | |
| 2 | 65.01101-0212A | BLOCK, CYLINDER | |
| 2 | 65.01101-0212B | BLOCK, CYLINDER | |
| 2 | 65.01101-0212C | BLOCK, CYLINDER | |
| 2 | 65.01101-0212D | CYLINDER BLOCK | |
| 3 | 65.04410-0016 | BUSH, CAM SHAFT | |
| 4 | 65.90302-0048 | Plug | |
| 5 | 06.15091-0326 | PLUG, CORE | |
| 5 | 65.91606-0037 | Plug | |
| 6 | 65.01105-1177A | BEARING | |
| 6 | 65.01105-1177B | BEARING | |
| 7 | 65.01105-1180A | BEARING | |
| 7 | 65.01105-1180B | BEARING | |
| 8 | 65.01105-1179B | BEARING | |
| 8 | 65.01105-1179C | BEARING | |
| 9 | 65.01105-1178A | CAP BEARING, THRUST | |
| 9 | 65.01105-1178B | CAP BEARING, THRUST | |
| 10 | 65.90020-0036B | BOLT, BEARING CAP | |
| 11 | 65.91710-0035 | RING, LOCATING | |
| 11 | 65.91710-0035B | RING, LOCATING | |
| 12 | 65.91606-0041 | Plug | |
| 12 | 65.91606-0041 | Plug | |
| 12-1 | 65.01601-0008 | NOZZLE, SPRAY | |
| 13 | 65.90310-0137 | SCREW | |
| 14 | 06.56190-0709 | Ring | |
| 15 | 65.90310-0136 | SCREW, PLUG | |
| 15 | 65.90310-0136A | SCREW, PLUG | |
| 16 | 06.56190-0718 | Ring | |
| 17 | 06.08092-2403 | Screw, plug | |
| 18 | 06.56190-0703 | RING, SEAL | |
| 19 | 65.90310-0131 | Screw | |
| 20 | 06.56190-0712 | Ring | |
| 21 | 65.90310-0149А | SCREW, PLUG M26X1.5 | |
| 22 | 06.56190-0726 | Ring | |
| 23 | 65.01201-0072 | LINER, CYLINDER | |
| 23 | 65.01201-0072А | LINER, CYLINDER | |
| 24 | 65.01601-6006 | OIL SPRAY NOZZLE | |
| 25 | 65.01601-6007 | OIL SPRAY NOZZLE | |
| 26 | 65.90001-0126 | BOLT, HEX. | |
| 27 | 06.16044-0208 | Washer | |
| 28 | 65.05405-7021 | RELIEF VALVE ASSY | |
| 29 | 06.56190-0704 | Ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
