2704-1541С
2704-1541С
1
1А
2
3
4
5
6
7
7
8
8
9
9
Позиция на иллюстрации
Заводской номер детали
Название детали
2704-1541С
2704-1541С
BUCKET ASSY-1.4 m3
1
BUCKET
Bucket
1А
713-00033
ADAPTER, TOOTH
2
713-00032
POINT, TOOTH
3
705-00006
PIN, LOCKING
4
114-00246
WASHER, LOCKING
5
2713-6034А
CUTTER, SIDE (R.H)
6
2713-6035А
CUTTER, SIDE (L.H)
7
S0574761
BOLT M24X3.0X70
8
S4013333
NUT M24
9
2114-1831
WASHER;HARDEN
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
