Каталог запасных частей к технике: Doosan S225LC-V. TRAVEL MOTOR
201
201
FLANGE
FLANGE
223
294
294
295
296
297
297
298
224
224
228
228
279
279
279
226
226
227
227
230
230
234
234
234
234
221
238
238
238
252
244
268
242
272
276
275
218
219
220
222
233
233
233
263
264
264
K9001047
K9001047
265
265
S8000111
S8000111
266
241
241
282
297
297
104
110
110
114
145
105
106
151
107
108
161
162
163
102
103
109
115
116
112
113
132
132
132
149
150
139
139
139
178
178
178
180
180
181
181
167
300
301
301
301
301
302
302
302
302
303
303
303
303
304
304
304
304
305
305
305
305
306
306
306
306
307
307
307
307
308
308
308
308
309
309
309
309
310
310
310
310
311
311
311
311
312
313
900
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 401-00454 | 401-00454 | TRAVEL DEVICE | |
| 401-00454A | 401-00454A | TRAVEL DEVICE | |
| 401-00454B | 401-00454B | TRAVEL DEVICE | |
| 401-00454C | 401-00454C | TRAVEL DEVICE | |
| RL | 1.215-00001 | REAR FLANGE ASSY | |
| K9001812 | K9001812 | REAR FLANGE ASSY | |
| RL1 | 1.215-00002 | KIT, REAR FLANGE | |
| K9001813 | K9001813 | KIT, REAR FLANGE | |
| 201 | 1.215-00003 | FLANGE, REAR | |
| FLANGE | FLANGE | Flange | |
| 223 | 1.424-00062 | Spool, main | |
| RL2 | 1.416-00026 | Stopper assy | |
| 294 | 1.416-00027 | STOPPER | |
| 295 | 1.424-00063 | Spool, main | |
| 296 | 1.129-00018 | SPRING | |
| 297 | 1.114-00542 | WASHER | |
| 298 | S6550100 | RING, SNAP | |
| 224 | 1.181-00059 | Plug, for main | |
| 228 | 1.131-00058 | Spring, for main | |
| 279 | S8000321 | O-ring | |
| 226 | 1.181-00067 | Plug, check | |
| 227 | 1.420-00013 | Valve, check | |
| 230 | 1.129-00006 | Spring, check | |
| 234 | S8002731 | O-ring | |
| 221 | 2181-1890D4 | Plug | |
| 238 | S8000181 | O-RING | |
| 252 | 2181-1116D2 | PLUG | |
| 244 | 2181-1116D1 | Plug | |
| 268 | S6250161 | Ball, steel | |
| 242 | 1.420-00014 | Valve, reducing | |
| 272 | 1.427-00031 | Seat, valve reducing | |
| 276 | 1.115-00141 | Ring, reducing | |
| 275 | 1.131-00062 | Spring, reducing v/v | |
| 218 | 1.427-00029 | Valve, seat t-type | |
| 219 | 1.420-00009 | Valve, t-type | |
| 220 | 1.131-00041 | Spring, t-type | |
| 222 | 1.115-00139 | Ring, t-type | |
| 233 | S8000091 | O-RING | |
| 263 | 422-00031 | Valve, two speed | |
| 264 | 116-00016 | STOPPER, T/SPEED | |
| K9001047 | K9001047 | Plug | |
| 265 | 411-00005 | RING, TWO SPEED | |
| S8000111 | S8000111 | O-RING | |
| 266 | 1.131-00099 | Spring, two speed | |
| 241 | S5700891 | Pin, parallel | |
| 282 | S2221471 | Bolt, socket | |
| 297 | 1.415-00005 | Orifice | |
| M | 1.401-00011 | MOTOR PART | |
| M1 | 1.441-00291 | Kit, cyl'd block and piston | |
| 104 | 1.441-00292 | Block, cyl'd | |
| 110 | 1.114-00305 | Washer | |
| 114 | 1.129-00019 | Spring, for cyl'd | |
| 145 | S6510700 | Ring, snap | |
| M11 | 1.409-00231 | Piston assy | |
| 105 | 1.409-00232 | Piston | |
| 106 | 1.355-00011 | Shoe | |
| 151 | 1.109-00135 | Roller | |
| 107 | 1.412-00093 | Plate, retainer | |
| 108 | 1.148-00016 | Ball, thrust | |
| M2 | 1.452-00004 | PISTON ASSY | |
| M2 | K9001814 | PISTON ASSY | |
| 161 | 1.409-00116 | Piston | |
| 162 | 1.355-00012 | Shoe | |
| 163 | 1.131-00042 | Spring | |
| 102 | 1.405-00022 | Shaft, main | |
| 103 | 1.412-00202 | PLATE, SWASH | |
| 109 | 1.412-00203 | Plate, timing | |
| 115 | 1.412-00061 | Plate, friction | |
| 116 | 1.412-00072 | Plate, mating | |
| 112 | 1.409-00115 | PISTON, PARKING | |
| 113 | 1.131-00055 | Spring, p/piston | |
| 132 | 1.180-00631 | Seal, oil | |
| 149 | 1.109-00147 | Bearing, ball | |
| 150 | 1.109-00026 | Bearing, ball | |
| 139 | S8002101 | O-ring | |
| 178 | S8011951 | O-ring | |
| 180 | S8000201 | O-RING | |
| 181 | S5701242 | Pin | |
| 167 | 1.540-00006 | Pivot | |
| R | 1.441-00293 | Kit, relief v/v block | |
| 300 | 1.441-00294 | Block, valve | |
| R1 | 1.426-00024 | Relief valve assy | |
| 301 | 1.429-00037 | Seat | |
| 302 | 1.424-00064 | Plunger | |
| 303 | 1.424-00065 | Rod | |
| 304 | 1.409-00233 | Piston | |
| 305 | 1.441-00295 | Body | |
| 306 | 1.181-00154 | Plug | |
| 307 | 1.129-00020 | Spring | |
| 308 | 1.114-00543 | Shim | |
| 309 | S8000181 | O-RING | |
| 310 | S8000181 | O-RING | |
| 311 | S8060181 | Ring, backup | |
| 312 | S2209661 | Bolt | |
| 313 | S5110501 | Washer, spring | |
| 900 | 2401-9082K | Seal kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
