5
5A
5A
5B
5C
5D
5E
5F
5G
5H
5I
5J
5K
5L
5M
5N
5O
5P
5P
2274-1008BKT
2274-1008BKT
Позиция на иллюстрации
Заводской номер детали
Название детали
604-00168
604-00168
TRACK ASSY
5
2274-1025E
TRACK SPRING ASSY
5A
2129-1236
SPRING
5B
2120-1105
BOLT
5C
2411-1001
RING;PISTON
5D
2180-9001
PACKING;U
5E
S6500400
RING;RETAINING
5F
2409-1010
ROD;PISTON
5G
S8010551
O-RING
5H
S2212066
BOLT;SOCKET M10X1.5X25
5I
2420-1242A
VALVE;GREASE
5J
2181-1618
FLANGE
5K
2440-1055B
CYLINDER
5L
2444-1015A
ROD
5M
2180-1026D21
O-RING
5N
2114-1369
SPACER
5O
2131-1109
WASHER
5P
2121-1208
NUT M45X2.0
2274-1008BKT
2274-1008BKT
SEAL KIT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
