Позиция на иллюстрации
Заводской номер детали
Название детали
195-01764А
195-01764А
SUPPORT ASSY
2
195-01770С
SUPPORT
3
195-01771В
SUPPORT
6
195-02173
SUPPORT
7
2120-2196D9
BOLT;SET M12X1.75X25
8
195-01896В
SUPPORT
9
195-01774В
SUPPORT
9
195-01774С
SUPPORT
11
195-01897А
SUPPORT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
