Каталог запасных частей к технике: Doosan S225LC-V. CABIN

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2-1
2-1
2-1
2-1
2-1
2-1
2-2
2-3
2-5
2-6
2-7
2-8
2-9
2-10
2-11
2-12
2-13
2-13
2-14
2-14
2-15
2-15
2-16
2-17
2-18
2-19
2-20
2-21
2-22
2-22
3
3
3
3
4
15
29
29
29
30
30
30
30
30
31
31
31
31
31
33
35
36
37
38
43
44
45
46
47
48
56
57
58
59
60
64
65
65
65
68
69
69
69
70
70
70
71
72
73
78
78
K1002429
K1002429
79
80
81
81
85
92
93
93
94
96
98
99
103
104
104
104
105
105
106
107
108
114
116
117
117
120
120
121
121
Позиция на иллюстрации Заводской номер детали Название детали
622-00177J 622-00177J CABIN ASS'Y
622-00177K 622-00177K CABIN ASS'Y
622-00177L 622-00177L CABIN ASS'Y
622-00177M 622-00177M CABIN ASS'Y
622-00177N 622-00177N CABIN ASS'Y
622-00177Q 622-00177Q CABIN ASS'Y
1 CAB Cab assy
2 622-00191B DOOR ASS'Y;FRONT
2 622-00191C DOOR ASS'Y;FRONT
2-1 622-00194B DOOR;FRONT
2-1 622-00194C DOOR;FRONT
2-2 903-00055A GLASS 6.76T
2-3 161-00395 DAMPER
2-5 125-00031A CATCH
2-6 161-00395 DAMPER
2-7 161-00395 DAMPER
2-8 161-00395 DAMPER
2-9 2161-2069 STOPPER
2-10 S4032633 NUT M10X1.25
2-11 2110-1347 BUSH 135L
2-12 125-00043 CATCH
2-13 2120-2166D36 BOLT M6X1.0X20
2-14 2114-2031D3 WASHER;SPRING M6
2-15 2114-1898D3 WASHER
2-16 133-00168 BAR
2-17 129-00146A SPRING
2-18 2160-1307 CAP;RUBBER
2-19 S4012533 NUT M8X1.25
2-20 2114-1898D2 WASHER M8
2-21 S5102503 WASHER;SPRING
2-22 K1000868 RUBBER 920L
3 2154-1033 ROLLER
4 903-00049 GLASS;FRONT LOWER
15 162-00025A STRIP;WEATHER 3800L
29 S3450973 SCREW M6X1.0X16
30 S5010313 WASHER;PLAIN
31 S5102303 WASHER;SPRING M6
33 2120-2166D5 BOLT M8X1.25X20
35 2197-1711 BRACKET;AUTO LOCK
36 2120-2166D4 BOLT M10X1.5X20
37 2125-9056 CATCH;AUTO LOCK
38 621-01990 COVER;AUTO LOCK
43 538-00009 MOTOR;WIPER
44 S3450833 SCREW M5X0.8X12
45 S5010213 WASHER PLAIN M5
46 S5102203 WASHER SPRING M5
47 2541-6020 WIPER ARM ASS'Y
48 507-00005 BLADE;WIPER
56 530-00212 HARNESS;CABIN LAMP
57 2891-1323 PLATE
58 S3450343 SCREW M3X0.5X10
59 S5020013 WASHER;PLAIN M3
60 S4010003 NUT M3X0.5
64 2161-2211 STOPPER;RUBBER
65 S3450993 SCREW M6X1.0X25
68 2161-2208 STOPPER;RUBBER RH
69 2140-1338 PIPE;SPACER
70 2114-1058D52 WASHER
71 2161-2207 STOPPER;RUBBER LH
72 2161-2210 STOPPER;RUBBER RH
73 2161-2209 STOPPER;RUBBER LH
78 2114-1855 WASHER ASS'Y
K1002429 K1002429 NOZZLE ASS'Y
79 S3643359 SCREW;TAPPING
80 195-01549A BRACKET
81 120-00226 BOLT;KNOB M8X1.25X30
85 2161-2212 STOPPER;RUBBER
92 621-01991 COVER;WIPER MOTOR
93 S3450953 SCREW M6X1.0X12
94 110-00230 BUSHING;RUBBER
96 2160-1310 BUSHING;RUBBER
98 2114-1898D2 WASHER M8
99 2114-1058D45 WASHER M10
103 2160-1026 TRIM
104 162-00027 STRIP;WEATHER L=920
104 2160-1023 RUBBER;CUSHION
104 162-00027 STRIP;WEATHER L=920
105 160-00038 RUBBER
106 142-00067 STRIKER
107 S3453118 SCREW M8X1.25X20
108 530-00251 HARNESS;W/MOTOR JOINT
114 2514-1013 HOLDER
116 195-02099 BRACKET
117 2161-2289 RUBBER;CUSHION
117 2161-2289А RUBBER, CUSHION
120 162-00030 STRIP;WEATHER
120 198-00036А STRIP, WEATHER
121 162-00031 TRIM;RUBBER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
