Каталог запасных частей к технике: Doosan Мини-погрузчик 450 Plus. 4150 Гидравлический насос
1
10
10
11
11
12
12
13
13
14
14
15
16
16
17
17
18
19
2
20
21
22
23
24
25
26
27
28
29
3
3
30
31
32
33
34
35
36
37
37
38
39
39
4
4
40
41
42
43
44
44
45
46
47
48
49
5
50
51
52
53
54
55
56
57
6
6
7
7
8
8
9
9
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | K1022809 | FLANGE;BEARING | |
| 10 | K1022818 | BEARING;CRADLE | |
| 11 | K1022819 | COIL;WIRE WITH | |
| 12 | K1022820 | O-RING | |
| 13 | K1022821 | SCREW | |
| 14 | K1022822 | GROUP;ROTARY | |
| 15 | K1022823 | CONTROL PLATE-R | |
| 16 | K1022824 | BEARING;ROLLER | |
| 17 | BUCKET;WELD | ||
| 18 | K1022826 | PISTON;POSITIONING | |
| 19 | K1022827 | ROD | |
| 2 | K1022810 | SHAFT;DRIVE | |
| 20 | K1022828 | COVER | |
| 21 | K1022829 | COLLAR;SPRING | |
| 22 | K1022830 | BUSH;SPACER | |
| 23 | K1022831 | SPRING;PRESSURE | |
| 24 | K1022832 | COLLAR;SPRING | |
| 25 | K1022833 | RING;RETAINING | |
| 26 | K1022834 | RING | |
| 27 | K1022835 | O-RING | |
| 28 | K1022836 | O-RING | |
| 29 | K1022837 | NUT;HEXAGON | |
| 3 | K1022811 | BEARING;ROLLER | |
| 30 | K1022838 | SCREW | |
| 31 | K1022839 | RING;GUIDE | |
| 32 | K1022840 | KIT;ROD SEAL | |
| 33 | K1022841 | PIN;THREADED | |
| 34 | K1022842 | NUT;SEAL LOCK | |
| 35 | K1022843 | CONTROL;HYD KIT | |
| 36 | K1022844 | CARTRIDGE;CONTROL | |
| 37 | K1022845 | VALVE;MAIN RELIEF | |
| 38 | K1022846 | VALVE;CHARGE RELIEF | |
| 39 | K1022847 | SCREW;ECCENTRIC | |
| 4 | K1022812 | RING;SEEGER | |
| 40 | K1022848 | DRIVE SHAFT-R | |
| 41 | K1022849 | CONTROL PLATE-L | |
| 42 | K1022850 | COUPLING | |
| 43 | BUCKET;WELD | ||
| 44 | K1022852 | BUSHING | |
| 45 | K1022853 | COUPLING | |
| 46 | K1022855 | KEY;SHAFT | |
| 47 | K1022856 | RING;SNAP | |
| 48 | K1022857 | PLATE;WEAR | |
| 49 | K1022858 | SET;WHEEL | |
| 5 | K1022813 | RING;SHAFT SEAL | |
| 50 | K1022859 | PIN;CYLINDER | |
| 51 | K1022860 | HOUSING | |
| 52 | K1022861 | PLATE;INTER | |
| 53 | K1022862 | O-RING | |
| 54 | K1022863 | O-RING | |
| 55 | K1022864 | SCREW | |
| 56 | K1022865 | KIT;GEAR PUMP | |
| 57 | K1022867 | O-RING | |
| 6 | K1022814 | RING;RETAINING | |
| 7 | K1022815 | CRADLE | |
| 8 | K1022816 | RING;SLIDE | |
| 9 | K1022817 | LINER;BEARING | |
| K1022798 | K1022798 | PUMP;HST | |
| K1022798A | K1022798A | PUMP;HST(JOYSTICK) | |
| K1022798B | K1022798B | PUMP;HST |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
