Каталог запасных частей к технике: Doosan Экскаватор SOLAR 175LC-V. 4160 Ходовой мотор
102
103
104
105
106
107
108
109
110
110
111
112
113
114
115
116
132
135
139
145
149
150
151
161
162
167
171
193
201
202
203
204
205
206
208
209
210
211
211
217
219
220
301
323
324
324
325
325
326
327
327
328
328
330
330
336
336
336
337
337
341
343
352
354
355
355
357
357
358
359
363
366
368
379
380
381
382
383
384
385
397
398
900
901
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 716689 | PISTON ASS'Y | |
| 102 | 135209 | SHAFT;MAIN | |
| 103 | 137369 | PLATE;SWASH | |
| 104 | 131149B | BLOCK;CYLINDER | |
| 105 | BUCKET;WELD | ||
| 106 | BUCKET;WELD | ||
| 107 | 131150 | PLATE;RETAINER | |
| 108 | 132323 | BALL;THRUST | |
| 109 | 132324A | PLATE;TIMING | |
| 110 | 116976 | WASHER | |
| 111 | 131356B | COLLAR;WASHER | |
| 112 | 131158 | PISTON;P.B | |
| 113 | 131159 | SPRING | |
| 114 | 131153 | SPRING | |
| 115 | 131160 | PLATE;FRICTION | |
| 116 | 116979 | PLATE;MATING | |
| 132 | 215823 | SEAL;OIL | |
| 135 | 228569 | O-RING | |
| 139 | 228570 | O-RING | |
| 145 | 215824 | RING;SNAP | |
| 149 | 229127A | BEARING;BALL | |
| 150 | 229128A | BEARING;BALL | |
| 151 | 131154 | ROLLER | |
| 161 | BUCKET;WELD | ||
| 162 | BUCKET;WELD | ||
| 167 | 131161 | PIVOT | |
| 171 | 131146 | PIN;PARALLEL | |
| 193 | 123744 | SPRING | |
| 201 | 131178 | VALVE | |
| 202 | 131179 | SLEEVE | |
| 203 | 131180 | RETAINER;SPRING | |
| 204 | 131181 | PLUG | |
| 205 | 131182 | SHIM | |
| 206 | 131183 | SPRING | |
| 208 | 201706 | O-RING | |
| 209 | 206597 | O-RING | |
| 210 | 201710 | O-RING | |
| 211 | 228576 | RING;BACK UP | |
| 217 | 228577 | RING;BACK UP | |
| 219 | 201729 | O-RING | |
| 220 | 228578 | SEAL;PISTON | |
| 301 | 137255 | FLANGE;REAR | |
| 323 | 138441 | SPOOL | |
| 324 | 204548 | PLUG | |
| 325 | 131167 | STOPPER | |
| 326 | 104126B | PLUG | |
| 327 | 105637 | VALVE | |
| 328 | 211668B | SPRING | |
| 330 | 123743 | SPRING | |
| 336 | 201733 | O-RING | |
| 337 | 201719 | O-RING | |
| 341 | 131177 | PIN;PARALLEL | |
| 343 | 200709 | BOLT;SOCKET | |
| 346 | 108061B | PLUG;PT | |
| 352 | 131170 | PLUG;RO | |
| 354 | 224308 | PLUG;PT | |
| 355 | 201710 | O-RING | |
| 357 | 131145 | PLUG;RO | |
| 358 | 201689 | O-RING | |
| 359 | 201700 | O-RING | |
| 363 | 131173 | SPOOL;2 SPEED | |
| 366 | 136254 | SPRING | |
| 368 | 200162 | BALL;STEEL | |
| 379 | 228574 | FILTER | |
| 380 | 131186 | PLUG | |
| 381 | 131165 | PISTON | |
| 382 | 131187 | PLUG | |
| 383 | 201749 | O-RING | |
| 384 | 201765 | O-RING | |
| 385 | 228582 | BALL;STEEL | |
| 397 | 116482A | ORIFICE | |
| 398 | 108064B | PLUG;PT | |
| 900 | 2401-9287KT | SEAL KIT | |
| 901 | 671B3100-03 | SEAL KIT;RELIEF VALVE | |
| 401-00034 | 401-00034 | TRAVEL DEVICE | |
| 401-00034A | 401-00034A | TRAVEL DEVICE | |
| 716691 | 716691 | RELIEF VALVE ASS'Y | |
| 716694 | 716694 | PISTON KIT;2 SPEED | |
| 718867 | 718867 | CYLBLOCK & PISTON KIT | |
| 719861 | 719861 | REAR FLANGE ASS'Y | |
| 719862 | 719862 | REAR FLANGE KIT | |
| 719864 | 719864 | TRAVEL MOTOR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
