К1006803А
1
2
3
4
5
5
5
5
5А
5А
5А
5А
5А
5А
Позиция на иллюстрации
Заводской номер детали
Название детали
К1006803А
К1006803А
ROTATING BEACON
1
160-00061
BUSH, MOUNTING
2
S5102503
WASHER;SPRING
3
S0508853
BOLT M8X1.25X20
4
530-00464
HARNESS
5
534-00062
LAMP;ROTATING BEACON
5
К1038193
BEACON, ROTATING
5А
515-00013
BULB;HALOGEN H1 24V 70W
5А
К9007240
BULB, HALOGEN 24V 70W
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
