K9004546A
1
2
3
4
5
6
7
7
7
7
7
7
8
9
10
11
14
18
19
Позиция на иллюстрации
Заводской номер детали
Название детали
K1018750B
K1018750B
RADIATOR ASSY
K9004546A
K9004546A
CAC ASSY
K1018750A
K1018750A
RADIATOR ASSY
1
K9004544
RADIATOR
2
K9004545
OIL COOLER
3
K9004546
CAC ASSY
4
K9004547
COOLER, FUEL
5
CHASSIS
FRAME
6
K9004548
SHROUD
7
K9004549
GUARD, FAN
7
K9006401
GUARD, FAN
8
K9004550
WIRE NET
9
K9004551
WIRE NET
10
K9004552
WIRE NET
11
K1010769
CAP;PRESSURE
14
K9003878
COCK ASS`Y
18
K9004553
BRACKET
19
K9004554
BRACKET
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
