Каталог запасных частей к технике: Doosan DX225LC. DUCT COVER
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
621-02902J
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
14
15
15
16
17
18
18
19
20
21
22
22
23
23
23
23
23
23
23
23
23
23
23
23
23
23
23
23
23
24
24
25
26
27
28
28
28
28
30
31
32
33
34
35
35
36
36
37
37
37
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 621-02902J | 621-02902J | SIDE COVER ASSY | |
| 1 | 621-02903C | COVER, SIDE FRONT | |
| 2 | 621-02905C | COVER, SIDE MID UPPER | |
| 3 | 621-02904C | COVER, SIDE MID LOWER | |
| 4 | 621-02909E | COVER, SWITCH | |
| 4 | 621-02909G | COVER, SWITCH | |
| 5 | 906-00002A | ASHTRAY ASM | |
| 6 | 621-02908B | HOLDER, CUP | |
| 7 | 213-00035B | DUCT, DEFROSTER SIDE | |
| 8 | 213-00030B | DUCT, FACE MID | |
| 9 | 213-00031E | DUCT, FACE REAR | |
| 10 | 213-00032B | DUCT, DEFROSTER FRONT | |
| 11 | 213-00033B | DUCT, DEFROSTER MID | |
| 12 | 213-00034E | DUCT, DEFROSTER REAR | |
| 13 | 213-00029C | DUCT, FACE FRONT | |
| 14 | 195-02768C | BRACKET, SWITCH COVER FRONT | |
| 14 | 195-02768E | BRACKET, SWITCH | |
| 15 | 195-02769C | BRACKET, SWITCH COVER REAR | |
| 15 | 195-02769E | BRACKET, SWITCH | |
| 16 | 415-00046B | LOUVER DEF SIDE | |
| 17 | 415-00045B | LOUVER DEF FRONT | |
| 18 | 195-02770C | BRACKET, CUP HOLDER | |
| 18 | 195-02770E | BRACKET, CUP | |
| 19 | 415-00044B | LOUVER FACE | |
| 20 | K1001068 | FOAM | |
| 21 | K1001069A | FOAM | |
| 22 | 195-02858C | BRACKET, MONITOR | |
| 22 | 195-02858E | BRACKET, MONITOR | |
| 23 | 2120-2166D52 | BOLT | |
| 24 | 2120-2166D53 | SCREW | |
| 25 | S3654523 | SCREW | |
| 26 | 2120-2166D23 | SCREW | |
| 27 | 621-02801 | COVER, SWITCH | |
| 28 | 621-03734A | COVER | |
| 30 | K1005007A | PLATE | |
| 31 | 2114-1898D14 | WASHER | |
| 32 | 2120-2166D5 | BOLT M8X1.25X20 | |
| 33 | 2114-2031D4 | WASHER;SPRING M8 | |
| 34 | К1009627 | PLATE | |
| 35 | 2120-2166D36 | BOLT M6X1.0X20 | |
| 36 | 2114-1898D5 | WASHER;PLAIN M6 | |
| 37 | К1010304 | BOLT, FLANGE | |
| 38 | 2120-2166D57 | BOLT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
