Каталог запасных частей к технике: Doosan DX225LC. DRIVING SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
4
5
10
11
15
16
17
18
19
19
20
21
22
22
22
23
23
23
30
31
32
33
34
35
36
37
37
40
41
42
Позиция на иллюстрации Заводской номер детали Название детали
1 65.02101-0069A SHAFT, CRANK
2 06.22022-1018 PIN, DOWEL 8M6X45
3 65.02115-0016 GEAR, CRANKSHAFT
4 65.01110-6140 METAL, MAIN
4 65.01110-6140A METAL, MAIN
5 65.01150-6008 Washer, thrust
10 65.02201-0002 DAMPER, VIBRATION
11 65.90020-0062B Bolt
15 65.02301-5148A FLYWHEEL ASSY
16 65.02301-0291A FLYWHEEL
17 65.02310-0006 GEAR;STARTING RING
18 65.02130-0004 BUSH, DRIVING
19 65.90020-0123 BOLT, COLLARED HEX
19 65.90020-0140A BOLT, COLLARED HEX.
20 65.02401-6032B CONNECTING ROD ASSY
21 65.02411-0009 BOLT, CONNECTING ROD
22 65.02410-0040 METAL, CON-ROD(STD)
22 65.02410-0042 METAL, CON-ROD(0.50)
22 65.02410-0041 METAL, CON-ROD(0.25)
23 65.02410-0050 METAL, CON-ROD(STD)
23 65.02410-0051 METAL, CON-ROD(0.25)
23 65.02410-0052 METAL, CON-ROD(0.50)
30 65.02501-0476 PISTON - GRADE
31 65.02501-0477 PISTON, A GRADE
32 65.02501-0478 PISTON, B GRADE
33 65.02503-0132A RING, PISTON
34 65.02503-0133A RING, PISTON
35 65.02503-0134 RING, PISTON
36 65.02502-0017A PIN, PISTON
37 06.29020-0125 Ring
40 65.02601-0225B PULLEY, V-BELT
41 65.90701-0099 WASHER
42 06.02106-0723 BOLT, SOCKET
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
