Каталог запасных частей к технике: Doosan DX140W. 4 OUTRIGGER PIPING - INDE
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
4
4
5
5
6
6
6
6
7
8
9
9
9
9
10
11
11
11
12
12
12
12
12
12
12
12
13
13
13
13-1
14
14
15
15
17
17
17
17
18
18
18
18
18
18
18
18
19
19
20
21
21
21
21
21
21
22
23
23
24
25
25
25
25
25
25
25
25
25
25
26
26
27
27
28
28
29
30
31
32
32
32
32
32
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 420212-00293 | 420212-00293 | OUTRIGGER PIPING | |
| 1 | S8000181 | O-RING | |
| 2 | S8030081 | O-RING | |
| 2 | S8030081 | O-RING | |
| 3 | 2181-4133D3 | ADAPTER | |
| 3 | 2181-4133D3 | ADAPTER | |
| 4 | K1006248 | Tee | |
| 5 | 121-00010D5 | Nut | |
| 6 | 181-00137 | Tee | |
| 6 | 181-00137 | Tee | |
| 7 | 2181-1951D1 | TEE PFO1/4-2PF1/4 | |
| 8 | 2181-1126D14 | ADAPTER;S PFO-PF1/4 | |
| 9 | 2181-4133D39 | Adapter | |
| 10 | 2181-1702D4 | ELBOW | |
| 11 | S8000111 | O-RING | |
| 12 | S8030061 | O-RING | |
| 13 | 420-00473A | VALVE, SOLENOID | |
| 13-1 | 300715-00008 | COIL | |
| 14 | S2213766 | Bolt, socket | |
| 15 | S5110603 | WASHER;SPRING | |
| 17 | K1013483 | ADAPTER | |
| 18 | DS0301032 | NUT | |
| 18 | DS0301064 | NUT | |
| 19 | DS2013680 | HOSE | |
| 19 | DS2013542 | HOSE | |
| 20 | DS2093013 | HOSE | |
| 21 | DS2093014 | HOSE | |
| 21 | DS2092054 | HOSE ASSY, HYDRAULIC | |
| 22 | 124-00209D2 | CLIP | |
| 23 | 124-00208D6 | CLIP D38/M8 | |
| 24 | 124-00208D9 | Clip | |
| 25 | K1001029 | BOLT | |
| 25 | K1001029 | BOLT | |
| 26 | 2160-1004D62 | BUSHING, RUBBER | |
| 27 | DS2013540 | HOSE | |
| 27 | DS2013779 | HOSE ASSY, HYDRAULIC | |
| 28 | DS2021143 | HOSE | |
| 28 | DS2021426 | HOSE ASSY, HYDRAULIC | |
| 29 | DS2013707 | HOSE | |
| 30 | DS2023183 | HOSE | |
| 31 | DS2013681 | HOSE ASSY, HYDRAULIC | |
| 32 | DS2011496 | HOSE | |
| 32 | DS2012880 | HOSE ASSY, HYDRAULIC | |
| 33 | 181-00131D3 | TEE |
