Каталог запасных частей к технике: Doosan DL220. WHEEL ASSY
1
1
1
1
1A
1A
1A
1A
2
2
2
2
K1011719
K1011719
K1011719
K1011719
3
3
3
3
3A
3A
3A
3A
4
4
4
4
K1011389
K1011389
K1011389
K1011389
5
5
5
5
5A
5A
5A
5A
6
6
6
6
K1011718
K1011718
K1011718
K1011718
7
7
7
7
7A
7A
7A
7A
8
8
8
8
K1036508
K1036508
K1036508
K1036508
9
9
9
9
9A
9A
9A
9A
10
10
10
10
K1054223
K1054223
K1054223
K1054223
11
11
11
11
11A
11A
11A
11A
12
12
12
12
K1054224
K1054224
K1054224
K1054224
13
13
13
13
13A
13A
13A
13A
14
14
14
14
K1054225
K1054225
K1054225
K1054225
15
15
15
15
15A
15A
15A
15A
16
16
16
16
K1054226
K1054226
K1054226
K1054226
17
17
17
17
17A
17A
17A
17A
18
18
18
18
K1054228
K1054228
K1054228
K1054228
19
19
19
19
19A
19A
19A
19A
20
20
20
20
K1054229
K1054229
K1054229
K1054229
21
21
21
21
21A
21A
21A
21A
22
22
22
22
K1024532
K1024532
K1024532
K1024532
23
23
23
23
23A
23A
23A
23A
24
24
24
24
900141-00049
900141-00049
900141-00049
900141-00049
25
25
25
25
25A
25A
25A
25A
26
26
26
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| K1011398 | K1011398 | WHEEL ASS'Y | |
| 1 | 278-00056 | RIM | |
| 1A | 2.422-00007 | VALVE, AIR | |
| 2 | K1009256 | TIRE 20.5-25-16PR(L3) | |
| K1011719 | K1011719 | WHEEL ASS'Y | |
| 3 | 278-00056 | RIM | |
| 3A | 2.422-00007 | VALVE, AIR | |
| 4 | K1011705 | TIRE 20.5-R25-L3 | |
| K1011389 | K1011389 | WHEEL ASS'Y | |
| 5 | 278-00084 | RIM | |
| 5A | 2.422-00007 | VALVE, AIR | |
| 6 | K1011196 | TIRE 17.5X25X12PR-L3 | |
| K1011718 | K1011718 | WHEEL ASS'Y | |
| 7 | 278-00084 | RIM | |
| 7A | 2.422-00007 | VALVE, AIR | |
| 8 | K1011704 | TIRE 17.5-R25-L3 | |
| K1036508 | K1036508 | WHEEL ASS'Y | |
| 9 | 278-00056 | RIM | |
| 9A | 2.422-00007 | VALVE, AIR | |
| 10 | K1033095 | TIRE (20.5X25X12PR-L3) | |
| K1054223 | K1054223 | WHEEL ASSY, 20.5R25 VKT-L2 | |
| 11 | 278-00056 | RIM | |
| 11A | 2.422-00007 | VALVE, AIR | |
| 12 | 276-00059 | TIRE 20.5R25VKT(L2) | |
| K1054224 | K1054224 | WHEEL, 20.5R25XHAT2-L3, MICHE | |
| 13 | 278-00056 | RIM | |
| 13A | 2.422-00007 | VALVE, AIR | |
| 14 | 4276-9052 | TIRE 20.5-25-XHA(L3) | |
| K1054225 | K1054225 | WHEEL ASSY, 20.5X25X16PR-L3 | |
| 15 | 4278-9040 | RIM | |
| 15A | 2.422-00007 | VALVE, AIR | |
| 16 | K1009256 | TIRE 20.5-25-16PR(L3) | |
| K1054226 | K1054226 | WHEEL ASSY, 20.5-R2-L3 | |
| 17 | 4278-9040 | RIM | |
| 17A | 2.422-00007 | VALVE, AIR | |
| 18 | K1011705 | TIRE 20.5-R25-L3 | |
| K1054228 | K1054228 | WHEEL ASSY | |
| 19 | 4278-9040 | RIM | |
| 19A | 2.422-00007 | VALVE, AIR | |
| 20 | K1033095 | TIRE (20.5X25X12PR-L3) | |
| K1054229 | K1054229 | WHEEL ASSY, 555/70R25 XLD70-1 | |
| 21 | 278-00056 | RIM | |
| 21A | 2.422-00007 | VALVE, AIR | |
| 22 | 276-00063 | TIRE 555/70R25XLD70-1(L3) | |
| K1024532 | K1024532 | WHEEL ASS'Y | |
| 23 | 278-00056 | RIM | |
| 23A | 2.422-00007 | VALVE, AIR | |
| 24 | 4276-9057 | TIRE 20.5-25-VMT(L3) | |
| 900141-00049 | 900141-00049 | WHEEL ASSY | |
| 25 | 278-00056 | RIM | |
| 25A | 2.422-00007 | VALVE, AIR | |
| 26 | 900138-00021 | TIRE, 20.5R25(L5) |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
