REAR VIEW CAMERA
LOADER ARM - ADD PIPING
CONTROL VALVE PIPING - ADD PIPING
CONTROL VALVE PIPING - ADD PIPING
WHEEL ASSY
WHEEL ASSY
301103-00003
1
2
3
4
5
6
31
32
33
34
35
36
43
44
Позиция на иллюстрации
Заводской номер детали
Название детали
301103-00003
301103-00003
CCTV ASSY, CHASSIS
1
537-00048
CAMERA, CCTV
2
621-01401
COVER, CAMERA
3
S0504653
BOLT M6X1.0X12
4
S4012333
NUT M6X1.0
5
S5102303
WASHER;SPRING M6
6
S5010313
WASHER;PLAIN
31
563-00009
CABLE, CAMERA
32
537-00047
MONITOR, CCTV
33
K1013941A
BRACKET
34
S0508453
BOLT M8X1.25X12
35
S5102503
WASHER;SPRING
36
S5010513
WASHER;PLAIN M8
43
530-00181
HARNESS, MONITOR JOINT
44
2128-1209D1
Clamp,metal
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
