Каталог запасных частей к технике: ChengGong CG-958H. Fan Control System
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z50G1801T17 | Motor Bracket Assembly | |
| 2 | 20491-36-16Z/20411-36-16ZX1T16GTX840 | Hose | |
| 3 | 2C9-36Z | Connector | |
| 4 | 1CH-36-33Z | Connector | |
| 5 | 20411-30-12Z/20491-30-12ZX1T12GTX1190 | Hose | |
| 6 | GB/T 70.1-2000 | Bolt | |
| 7 | CBQz-F532-AFфL | Gear Pump | |
| 8 | FL-20Z | Flange | |
| 9 | GB/T93-1987 | Valve | |
| 10 | GB/T5783-2000 | Connector | |
| 11 | FL-12Z | Flange | |
| 12 | GB/T93-1987 | Valve | |
| 13 | GB/T5783-2000 | Connector | |
| 14 | GB/T97.1-2002 | Washer 10 | |
| 15 | 87342-12-12TZ/20512-30-12TZX4SP12AGX760 | Hose | |
| 16 | KDMD-30-14-30FALNZ | Connector | |
| 17 | 4M-14WDZ | Plug | |
| 18 | TLPG14-428-DKL | Clip | |
| 19 | 20592-30-12TZ/20512-30-12TZX4SP12AGX500+RNL | Hose | |
| 20 | 20491-30-12T/20411-30-12TX1T12AGX2185+RNL | Hose | |
| 21 | 1CG-30-16Z | Connector | |
| 22 | WM09A1C310L07TB122HGNNR2320001M | Hydraulic Motor | |
| 23 | 1DG-30-12Z | Connector | |
| 24 | 1CFL9-36-20Z | Connector | |
| 25 | 2C9-30Z | Connector | |
| 26 | 20441-30-12TZ/20411-30-12TZXIT12AGX940 | Hose | |
| 27 | GB/T93-1987 | Valve | |
| 28 | GB/T97.1-2000 | Cushion 8 | |
| 29 | GB/T5782-2000 | Bolt | |
| 30 | GB/T5783-2000 | Connector | |
| 31 | Z50G180000002T17 | Plate | |
| 32 | 6C-30LNZ | Connector | |
| 33 | TTPG3-430-DKL | Clip |
