Каталог запасных частей к технике: ChengGong CG-958G. Z50G08T7 Steeing System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
39
40
41
41
42
42
42
43
43
44
45
46
47
48
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Hose d84X270 | Hose d84X271 | |
| 2 | Clampd80~d100 | Clamp d80~d101 | |
| 3 | Z50G0801T7 | Suck Tube Assembly | |
| 4 | T6DCM-B24-B05-3R23-C1 | Pump | |
| 5 | FL-20 (d12) | Connector | |
| 6 | 1DFL9-36-20FA | Connector | |
| 7 | 2HD-42-36 | Connector | |
| 8 | S2502.0B | Valve | |
| 9 | 1DM-36-42WD | Connector | |
| 10 | 2D9-36 | Connector | |
| 11 | 20512-36-16TX4SP16TKAG X580 | Hose | |
| 12 | Z50G0802T7 | Valve | |
| 13 | Z50G0803T7 | Lash-up Clamp | |
| 14 | 20441-30-12/20491-30-1 2X1T12GTX840V90° | Hose | |
| 15 | 20411-22-12X2T12GTX650 | Hose | |
| 16 | 20411-30-12/20491-30-1 2X2T12GTX1050 | Hose | |
| 17 | 20411-14-04/20491-14-0 4X1T04GTX1170 | Hose | |
| 18 | 1CM-30-20WD | Connector | |
| 19 | 1CM-26-20WD | Connector | |
| 20 | BZZ1-1000/FK-15/20 | Steering Unit | |
| 21 | 1CM-14-12WD | Connector | |
| 22 | 20411-26-10/20491-26-1 0X2T10GTX400 | Hose | |
| 23 | 20411-26-10/20491-26-1 0X2T10GTX450 | Hose | |
| 24 | AC-26 (CG) | Connector | |
| 25 | Z50E080000001T46 | Gear into batten | |
| 26 | 20411-26-08TX2T8GTX640 | Hose | |
| 27 | 20411-26-08T/20441-26-08TX2T8GTX650 | Hose | |
| 28 | 20491-26-08T/20441-26 -08TX2T8GTX720V225° | Hose | |
| 29 | 20411-26-08T/20441-26 -08TX2T8GTX820 | Hose | |
| 30 | 1CM-26-22WD | Connector | |
| 31 | CL90X45/488 EG-00A | Steering Cylinder | |
| 32 | CG50.8.6 | Hinge Pin | |
| 33 | TTPG1-430 | Clamp | |
| 34 | TTPG1-325 | Clamp | |
| 35 | 20411-30-12/20491-30-12X1T12GTX1440 | Hose | |
| 36 | 20411-18-04/20441-14-04X1T04GTX900 | Hose | |
| 37 | SAE5/8-11 UNC 50 | Bolt | |
| 38 | GB93-87 | Washer 8 | |
| 39 | GB5783-86 | Bolt M8x20 | |
| 40 | SAE7/16-14 UNC 30 | Bolt | |
| 41 | GB93-87 | Washer 8 | |
| 42 | GB93-87 | Washer 8 | |
| 43 | GB5783-86 | Bolt M8x20 | |
| 44 | GB5783-86 | Bolt M8x20 | |
| 45 | GB5783-86 | Bolt M8x20 | |
| 46 | 2C-26 | Connector | |
| 47 | 2C9-26 | Connector | |
| 48 | 2C9-14 | Connector | |
| 49 | Z50G080000001T7 | Gasket | |
| 50 | 1CM-16-14WD | Connector | |
| 51 | CC-16 | Connector | |
| 52 | 7MC-14-16 | Connector | |
| 53 | PT-3 | Pressure-testing | |
| 54 | 2C9-30 | Connector |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
