Каталог запасных частей к технике: ChengGong CG-956G. Z5EH15T4 Electrical Component

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
2
2
3
3
4
5
5
6
6
7
8
8
9
10
10
11
11
12
13
13
13
14
14
15
15
16
16
16
17
18
19
20
20
20
20
21
21
21
21
22
22
23
23
24
24
24
25
25
26
26
26
26
27
27
28
28
29
29
30
30
30
31
31
31
32
32
32
33
33
33
34
35
36
37
37
37
38
38
38
38
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
45
46
47
47
48
48
49
49
50
50
51
52
52
53
53
54
54
55
55
56
56
57
58
58
59
60
60
61
62
63
64
65
66
67
67
68
68
69
69
69
71
71
72
72
Позиция на иллюстрации Заводской номер детали Название детали
1 DK231/24V Battery disconnect relay
2 6-QW-120B Battery
3 CAT-4N3138M Starting motor
4 HG4735 Fuse box
5 MZJ-50A Steering relay
6 CAT-3T6352 Alternator
7 ChargeIndicator Battery charge indicator
8 JK406 Start key
9 JQ201S-PLO Trans. Neutral Relay
10 Shutdownvalve Shutdown valve
11 DW-2 Ttemp. Gauge
12 WG-2 Temp. Sensor
13 DW-2 Ttemp. Gauge
14 WG-2 Temp. Sensor
15 DV-2 Voltmeter
16 701DN001O1248D Hour meter
17 YT-202 Pressure gauge
18 YT-202 Pressure gauge
19 YT-202 Pressure gauge
20 DR-2 Oil Level gauge
21 RG-4 Oil Level sensor
22 JK981-000-3.67 Rear Light SW.
23 CG70W Working lamp
24 JK981-000-3.67 Rear Light SW.
25 CabLight Cab light
26 JQ603B Backup Flasher
27 303A Lamp SW
28 Indicator Turn indicator
29 Indicator Turn indicator
30 JK9073 Emergency light SW.
31 CG21W Turn light
32 CG21W Turn light
33 8W Small light
34 GaugeLight Gauge light inside
35 CG70W Working lamp
36 8W Small light
37 JN150 Braking Light
38 BrakingLight Braking light
39 JK802B Horn Button
40 DL224EG Horn
41 JK981-000-4.66/4.67 Downshift selector
42 10W Wall light
43 JK981-045-2.5 Front Wiper SW.
44 CG50E-A Front Wiper
45 JK981-045-2.28 Rear Wiper SW.
46 CG50E-A Front Wiper
47 CigaretteLighter Cigarette lighter
48 CG35H-1 Air conditioner
49 CryogenPressureSW Cryogen pressure sw
50 BlowerFanMotor Blower fan motor
51 Valve Valve
52 ZDTSK-1 Lift kick-out control
53 Outvalve Lift kick-out valve
54 ZDSPK-1 Bucket positioned control
55 BucketValve Bucket positioned valve
56 Liftfloatingvalve Lift floating valve
57 EST-17TE/ZF200 Transmission control
58 DW-2/ZF200 Shift handle
59 ZF200 Transmission Sol. group
60 SpeedSensor Speed sensor
61 Fuse Fuse
62 PS61-50/35bar Trans. Downshift sw
63 PS61-50/69bar Parking brake sw
64 BrakeIndicator Parking brake indicator
65 JQ201S-PLO Trans. Neutral Relay
66 JQ603B Backup Flasher
67 3T1815 Backup Alarm
68 Jk981-000-3.40 Work warning light switch
69 WorkLight Work warning light
70 BrakeIndicator Parking brake indicator
71 TK-721 Radio
72 Antenna Antenna
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
