Каталог запасных частей к технике: ChengGong CG-956G. Z50E17T45 Air-conditioner System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | YTCG35H-81030000 | Evaporator assembly | |
| 2 | YTCG50E-II-81010000 | Condenser Assembly | |
| 3 | YTCG35H-81050300 | Hose | |
| 4 | HFC-R134a | R134a | |
| 5 | YTCG35H-81020100 | Storage Bottle | |
| 6 | YTCG50E-II-81050700 | Connector assembly | |
| 7 | YTCG35H-81050100 | Hose | |
| 8 | YTCG35H-81050400 | Hose | |
| 9 | AV13Li-1250 | Three-cornered strap | |
| 10 | SD5H14 | Compressor | |
| 11 | Z50G130501001 | Compressor Bracket | |
| 12 | YTCG35H-81050500 | Inlet Pipe | |
| 13 | YTCG35H-81050600 | Outlet Pipe | |
| 14 | Z3/8 | Valve | |
| 15 | Z50G130501002 | Adjustive seat | |
| 16 | Z50G130501002 | Adjustive seat | |
| 17 | GB5783-86 | Bolt M8x20 | |
| 18 | GB848-85 | Washer 12 | |
| 19 | GB93-87 | Washer 8 | |
| 20 | GB5783-86 | Bolt M8x20 | |
| 21 | GB848-85 | Washer 12 | |
| 22 | GB93-87 | Washer 8 | |
| 23 | Hoop | Hoop | |
| 24 | GB5782-86 | Bolt M10x130 | |
| 25 | GB6170-86 | Nut M6 | |
| 26 | GB93-87 | Washer 8 | |
| 27 | GB5783-86 | Bolt M8x20 | |
| 28 | GB6170-86 | Nut M6 | |
| 29 | GB93-87 | Washer 8 | |
| 30 | GB5783-86 | Bolt M8x20 | |
| 31 | GB5782-86 | Bolt M10x130 | |
| 32 | GB5782-86 | Bolt M10x130 | |
| 33 | GB5782-86 | Bolt M10x130 | |
| 34 | GB6170-86 | Nut M6 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
