Каталог запасных частей к технике: ChengGong CG-956G. Hydraulic System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z5EH1001T4 | Hydraulic oil tank | |
| 2 | Z5EH1004T4 | Manul-set box | |
| 3 | Z5EH1003T4 | Valve | |
| 4 | Z50E1003T38 | Steel Tube Assembly | |
| 5 | Z50E1004T38 | Steel Tube Assembly | |
| 6 | 87391-16-16SCX2SC16SYX1250V90 | Hose | |
| 7 | 87391-16-16SCX2SC16SYX1300V0 | Hose | |
| 8 | Z50F1008T1 | Steel tube assembly | |
| 9 | Z50F1009T1 | Steel tube assembly | |
| 10 | 87391-24-24X1M24GTX1850V180°+RS1500 | Hose | |
| 11 | Z50F1016 | Clip | |
| 12 | FL-24 | Flange | |
| 13 | 4C-22 | Plug | |
| 14 | 20411-22-08X1T08GTX1200 | Hose | |
| 15 | GB93-87 | Washer 8 | |
| 16 | GB5783-86 | Bolt M8x20 | |
| 17 | Z50F1002T4 | Steel tube assembly | |
| 18 | 20411-30-12/20491-30-12X1T12GTX2640 | Hose | |
| 19 | 20491-30-12/20441-30-12X1T12GTX2120V180 | Hose | |
| 20 | Z50E100000001 | Clamp | |
| 21 | GB93-87 | Washer 8 | |
| 22 | GB5783-86 | Bolt M8x20 | |
| 23 | LH-ZL50G-I | Hydraulic oil radiator | |
| 24 | GB5783-86 | Bolt M8x20 | |
| 25 | GB93-87 | Washer 8 | |
| 26 | Z50G1012T1 | Steel tube assembly | |
| 27 | 20512-42-16/87392-20-16X4SH16AGX690 | Hose | |
| 28 | Z50G1003T1 | Steel tube assembly | |
| 29 | GB93-87 | Washer 8 | |
| 30 | GB5783-86 | Bolt M8x20 | |
| 31 | Z50G1011T1 | Conflux seat assembly | |
| 32 | 1DFL9-42-20 | Connector | |
| 33 | FL-20 | Flange | |
| 34 | P7600-F160LX | Gear pump | |
| 35 | 87312-20-20/87392-24-20X4SM20GJX2150+RS1500 | Hose | |
| 36 | Z50F1015A | Clip | |
| 37 | Z50F100000001 | Plate | |
| 38 | 87342-12-12/87392-12-12X4SM12GJX1300V2700 | Hose | |
| 39 | 87342-12-12/87392-12-12(H130)X4SM12GJX1300V270° | Hose | |
| 40 | Z50F1006T4 | Cylinder | |
| 41 | Z50F1010T4 | Tilting cylinder | |
| 42 | Z50F1007T4 | Cylinder | |
| 43 | Z50F1005T1 | Valve | |
| 44 | 87342-12-12/87392-12-12X4SM12GJX1300V900 | Hose | |
| 45 | 87342-12-12/87392-12-12(H130)X4SM12GJX1300V90° | Hose | |
| 46 | 2C9-16 | Connector | |
| 47 | 1CL-16-18 | Connector | |
| 48 | 20411-16-06/20491-16-06X1T06GTX580 | Hose | |
| 49 | Z50F1029 | Clip | |
| 50 | GB93-87 | Washer 8 | |
| 51 | GB5783-86 | Bolt M8x20 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
