Каталог запасных частей к технике: ChengGong CG-956G. FSD302 Steering control assembly
1
2
3
4
5
6
8
9
10
11
13
14
15
16
17
18
19
20
21
22
24
25
26
27
28
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | FSR304A-01 | Steering wheel assembly | |
| 2 | FSR304A-02 | Cupreous washer assembly | |
| 3 | FSR304A-03 | Cupreous loop assembly | |
| 4 | FSR304A-04 | Above bracket | |
| 5 | FSR304A-05 | Steering axis assembly | |
| 6 | FSR304A-06 | Lower bracket | |
| 8 | FSR304A-00000001 | Cover | |
| 9 | LT01012 | Lighter | |
| 10 | FSR304A-00000002 | Left cover | |
| 11 | FSR304A-00000003 | Cover | |
| 13 | FSR304A-00000005 | Panel | |
| 14 | FSR304A-00000006 | Above cover | |
| 15 | FSR304A-00000007 | Right cover | |
| 16 | FSR304A-00000008 | Engine start switch | |
| 17 | FSR304A-00000009 | Cover | |
| 18 | 700М | Light switch | |
| 19 | FSR304A-00000010 | Spring | |
| 20 | FSR304A-00000011 | Spring | |
| 21 | FSR304A-00000012 | Nail | |
| 22 | FSR304A-00000013 | Front cover | |
| 23 | FSR304A-00000014 | Rubber ringer | |
| 24 | FSR304A-00000015 | Rear cover | |
| 25 | FSR304A-00000016 | Spring | |
| 26 | FSR304A-00000017 | Handle | |
| 27 | FSR304A-00000018 | Lower cover | |
| 28 | FSR304A-00000019 | Switch box | |
| 31 | FSR304A-00000022 | Spring | |
| 32 | FSR304A-00000023 | Linker | |
| 33 | FSR304A-00000024 | Bolt | |
| 34 | FSR304A-00000025 | Hold up loop | |
| 35 | FSR304A-00000026 | Baffle | |
| 36 | GB/T41-1986 | Nut | |
| 37 | GB/T70-1985 | Bolt | |
| 38 | GB/T818-1985 | Bolt | |
| 39 | GB/T819-1985 | Bolt | |
| 40 | GB/T818-1985 | Bolt | |
| 41 | GB/T818-1985 | Bolt | |
| 42 | GB/T41-1986 | Nut | |
| 43 | GB/T818-1985 | Bolt | |
| 44 | GB/T95-1985 | Washer | |
| 45 | GB/T93-1987 | Valve | |
| 46 | GB/T818-1985 | Bolt | |
| 47 | GB/T93-1987 | Valve | |
| 48 | GB/T95-1985 | Washer | |
| 49 | GB/T93-1987 | Valve | |
| 50 | GB/T95-1985 | Washer | |
| 51 | GB/T818-1985 | Bolt | |
| 52 | GB/T818-1985 | Bolt | |
| 53 | GB/T818-1985 | Bolt | |
| 54 | GB/T818-1985 | Bolt | |
| 55 | GB/T819-1985 | Bolt | |
| 56 | GB/T93-1987 | Valve | |
| 57 | GB/T70-1985 | Bolt | |
| 58 | GB/T95-1985 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
