Каталог запасных частей к технике: ChengGong CG-956C. ZL956C-150/80 Lift Cylinder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | ZL50EIII150/80H.1.00 | Cylinder | |
| 2 | JB/ZQ3870-86 | Anti-dust plug | |
| 3 | ZL50E160/80H-1 | Lock key for axis | |
| 4 | GB895.2-86 | Ring | |
| 5 | ZL50EIII150/80H-1 | Piston | |
| 6 | CKW1500 | Assembled seal for bore | |
| 7 | Ф150x15x2.5 | Support Ring | |
| 8 | GB1235-76 | O-Ring 16x2.4 | |
| 9 | ZL50E160/80H-4 | Piston Rod | |
| 10 | ZL50EIII150/80H-2 | Cover | |
| 11 | GB1235-76 | O-Ring 16x2.4 | |
| 12 | ZL35F150/75H-3 | Sheath | |
| 13 | 85x9.5x2.5 | Support Ring | |
| 14 | CKS0800 | Ring | |
| 15 | D-2-ф80x95x9 | Ring | |
| 16 | ZL50EII160/80H-7 | Block Ring | |
| 17 | DH80-6/8 | Ring | |
| 18 | ZL50E160/80H-8 | Fork-shape Pole End | |
| 19 | ZL50E160/80H.2.00 | Ring | |
| 20 | ZL50E160/80H-9 | Shift Cover | |
| 21 | ZL50E160/80H-3 | Buffering Cover | |
| 22 | ZL50EIII150/80H-3 | Clamp | |
| 23 | GB5780-85 | Screw | |
| 24 | Q/CGY-MP01 | Nameplate | |
| 25 | GB109-86 | Rivet d2x4 | |
| 26 | GB70-85 | Screw M12x80 | |
| 27 | GB879-86 | Pin 8x35 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
