Каталог запасных частей к технике: ChengGong CG-956C. Z5E303T4 Transmission
7
14
15
16
43
44
45
46
47
48
49
50
56
57
66
78
80
81
85
86
88
89
93
94
95
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z50E0301 | Powe Shift Pump | |
| 2 | ZL50.3.2A | Range Gear Assembly | |
| 3 | ZL50.3.3 | Exceed Clutch | |
| 4 | ZL50.3.4A | Reverse-Range Plate Assembly | |
| 5 | ZL50.3.5 | Driving Disk | |
| 6 | ZL50.3.6 | Disk Bracket Assembly | |
| 7 | Z5E30301 | Oil Assembly | |
| 8 | ZL50.3.8T42 | Driving Assembly | |
| 9 | ZL50.3.9A | 1st-Range Plate Assembly | |
| 10 | ZL50.3.10 | 1st-Range Gear Assembly | |
| 11 | ZL50.3.11B | 1st-Range Cylinder Assembly | |
| 12 | ZL50.3.12 | 1st-Range Piston Assembly | |
| 13 | ZL50.3.13 | Reverse-Rang Piston Assembly | |
| 14 | ZL50.3.14 | Air Cover Assembly | |
| 15 | BF25 | Control Valve Assembly | |
| 16 | ZL50.3.16A | Bracket | |
| 17 | Z55S0303T2 | Oil Pan | |
| 18 | Z50E0301T56 | Handle Brake Assembly | |
| 19 | ZL50.3-38 | Adjusting Shim | |
| 20 | ZL50.3-1 | Seal Gasket | |
| 21 | Z50F030000001T4 | Case | |
| 23 | Z50E030000002 | Shaft Gear | |
| 25 | ZL50.3-6 | Plain Washer | |
| 26 | ZL50.3-7 | Driving Disk | |
| 27 | ZL50.3-8 | Rear Connecting Flange | |
| 28 | ZL50.3-9 | Press Plate | |
| 29 | ZL50.3-10 | Seal Seat | |
| 30 | ZL50.3-11A | Output Shaft | |
| 31 | ZL30B.3-26 | Threaded Plug | |
| 33 | ZL50.3-14 | Oil Disk | |
| 34 | ZL50.3-15T42 | Output Shaft Gear | |
| 35 | ZL50.3-16 | Bear Bushing | |
| 36 | ZL50.3-17A | Bear Bushing | |
| 37 | Z50E030000005 | Front Connecting Flange | |
| 39 | ZL50.3-20C | End Cover | |
| 40 | ZL50.3-21 | Middle Cover | |
| 41 | ZL50.3-22 | Reverse-Spring | |
| 42 | ZL50.3-23 | Spring Rod | |
| 43 | ZL50.3-24 | Plug | |
| 44 | ZL50.3-25 | Sealing Ring | |
| 45 | ZL50.3-26 | Pin | |
| 46 | ZL50.3-27A | V-Washer | |
| 47 | Z50E030000003 | Bearing Support | |
| 48 | Z50E030000004 | Driving Shaft | |
| 49 | ZL50.3-30A | Driving Gear | |
| 50 | ZL50.3-31 | Plate | |
| 51 | ZL50.3-32 | Adjusting Shim | |
| 52 | ZL50.3-33 | Nut | |
| 53 | ZL50.3-34 | Bear Bushing | |
| 54 | ZL50.3-35 | O-Ring | |
| 56 | ZL50.3-37A | Plain Washer | |
| 57 | YJSW315.6A-12A | Threaded Plug | |
| 59 | 6012 | Bearing | |
| 60 | GB/T5783-2000 | Connector | |
| 61 | GB/T93-87 | Washer 20 | |
| 63 | 6210NR | Bearing | |
| 65 | GB/T893.1-86 | Snap Ring | |
| 66 | GB/T5783-2000 | Connector | |
| 67 | GB/T5783-2000 | Connector | |
| 68 | GB/T5783-2000 | Connector | |
| 69 | HG4-692-67 | Oil Seal PD60x80x12 | |
| 70 | GB3452.1-82 | O-Ring 28x2.65 | |
| 71 | GB/T893.1-86 | Snap Ring | |
| 72 | GB/T276-94 | Bearing | |
| 73 | GB3452.1-82 | O-Ring 28x2.65 | |
| 74 | GB/T5783-2000 | Connector | |
| 75 | GB/T848-2002 | Washer | |
| 76 | GB/T93-87 | Washer 20 | |
| 77 | GB/T5783-2000 | Connector | |
| 78 | GB/T93-87 | Washer 20 | |
| 79 | GB3452.1-82 | O-Ring 28x2.65 | |
| 80 | GB/T825-88 | Screw | |
| 81 | GB/T119.2-2000 | Pin | |
| 83 | GB/T5783-2000 | Connector | |
| 84 | GB/T93-87 | Washer 20 | |
| 85 | GB/T5782-2000 | Bolt | |
| 86 | 1305C-010 | Oil Plug | |
| 87 | JB/T982-77 | Washer | |
| 88 | 6211 | Bearing | |
| 89 | GB/T1096-2003 | Key | |
| 91 | GB/T91-2000 | Pin 4.5х45 | |
| 93 | GB3452.1-92 | O-Ring 140x3.55 | |
| 94 | GB/T5782-2000 | Bolt | |
| 95 | GB/T1337-88 | Nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
