Каталог запасных частей к технике: ChengGong CG-956C. Z50E309T4 Braking System
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
32
33
34
35
36
37
38
39
40
41
42
43
43
44
44
44
45
45
45
46
47
47
48
48
49
49
50
51
52
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z5E30901T1 | Stay Break Bracket | |
| 2 | Z5E30901T4 | Accordant junction Pipe | |
| 3 | Z5E30902T1 | Accentor assm | |
| 4 | Z5E30901T3 | Air Break Valve | |
| 5 | Z5E30904T1 | Hand Break Valve | |
| 6 | Z5E30905T1 | Oil Water Separator | |
| 7 | Z5E30906T1 | Accordant junction Value | |
| 8 | Z5E30904T46 | Pipe | |
| 9 | Z5E30904 | Accentor Pipe | |
| 10 | CG50.9.12 | Hose | |
| 11 | CG50.9.19 | Connector | |
| 12 | CG50.9.18 | Pipe | |
| 13 | CG50.9.11 | Pipe | |
| 14 | CG50.9.114 | Pipe | |
| 15 | Z5E30904T4420291-22Z/20211 | Pipe | |
| 16 | 18-08ZX1T08GTX400 | Pipe | |
| 17 | 1QE-18-22Z | Hose | |
| 18 | CG50.9-3 | Pipe | |
| 19 | 20711-18-06ZX1T06GTX1400 | Pipe | |
| 20 | 20711-18-06ZX1T06GTX1700 | Pipe | |
| 21 | CQ-18Z | Hose | |
| 22 | 20711-18-06ZX1T06GTX230 | Pipe | |
| 23 | CQ-18Z | Hose | |
| 24 | 1QH9-18-220GZ | Hose | |
| 25 | 1QH-18-22Z | Hose | |
| 26 | НР4..0-60 | Hose | |
| 27 | 1QH9-120GZ | Hose | |
| 28 | 1QH-12Z | Hose | |
| 29 | 20711-14-04ZX1T04GTX1750 | Pipe | |
| 30 | 6C-16/LNZ20411-16-04Z/2 | Hose | |
| 31 | 0791-14-04ZX1T04GTX215V27020711-16-04Z/2 | Pipe | |
| 32 | 0791-14-04ZX1T04GTX2600 | Pipe | |
| 33 | 1QN-10-027 | Hose | |
| 34 | Z5E1509T38 | Pressure instrument tube | |
| 35 | 20711-14-04/2041Ы6-04Х1Т04GTX950 | Pipe | |
| 36 | 20711-14-04/2041Ы6-04Х1Т04GTX950 | Pipe | |
| 37 | 20411-14-04/2071Ы4-04Х1Т04GTX700 | Pipe | |
| 38 | 20791-10-02/20711-10-02X1Y02PK1010 | Pipe | |
| 39 | 20791-10-02/20711-10-02X1Y02РК1010 | Pipe | |
| 40 | 1QN-10-027 | Hose | |
| 41 | 2Q9-10Z20711-14-04Z/2 | Connector | |
| 42 | 0791-14-04ZX1T04GTX1200 | Pipe | |
| 43 | K0608-14Z | Clamp | |
| 44 | GB/T93-1987 | Valve | |
| 45 | GB/T5783-2000 | Connector | |
| 46 | K0608-18Z | Clip | |
| 47 | GB/T5783-2000 | Connector | |
| 48 | GB/T93-1987 | Valve | |
| 49 | GB/T97.2-2002 | Washer 24 | |
| 50 | GB/T6170-2000 | Nut M14 | |
| 51 | GB/T6170-2000 | Nut M14 | |
| 52 | GB/T93-1987 | Valve |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
