Каталог запасных частей к технике: ChengGong CG-938H. Implement Hydraulic System
1
2
3
4
5
6
7
8
8
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
11
11
12
13
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
25
25
25
26
27
29
29
29
30
31
32
33
34
35
36
37
37
37
38
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
70
71
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z38G1001T2 | Hydraulic Oil Tank | |
| 2 | Z38G1015T1 | Steel Tube Assembly | |
| 3 | Z38G1002T2 | Steel Tube Assembly | |
| 4 | 87392-12-12(Н130)Z/87392-12-12ZX4 SP12X940V270 | Hose | |
| 5 | FL-12Z (4 3/8” Х16-32) 20542-42-16TZ/87342-16-16ZX4SP16X | Flange | |
| 6 | 1010V270 87342-16-16Z/20512-42-16ZX4SP16X1 | Hose | |
| 7 | 360+RNL | Hose | |
| 8 | FL-16Z | Flange | |
| 9 | GB/T 5783-2000 | Bolt | |
| 10 | GB/T 93-1987 | Washer | |
| 11 | FL-20Z | Flange | |
| 12 | Z38G100000001T1 | Flange | |
| 13 | Z38G100000002T1 | Plate | |
| 14 | GB/T 5783-2000 | Bolt | |
| 15 | 87341-20-20Z/20411-45-20TZX1T20X1 070 | Hose | |
| 16 | 20411-45-20TZ/87341-20-20ZX1T20X1 180RNL | Hose | |
| 17 | Z38G1004T1 | Ride Control Valve Assembly | |
| 18 | Z38G1014T1 | Accumulator Assembly | |
| 19 | 20592-36-12TZX4SH12X650V0/STC | Hose | |
| 20 | Z38G1003T1 | Multi-way valve Assembly | |
| 21 | 87312-12-12Z/87392-12-12ZX4SH12X9 00RNLDCN | Hose | |
| 22 | 87312-12-12Z/87392-12-12(Н130)ZX4 SH12X1020RNLDCN | Hose | |
| 23 | 87312-12-12Z/87392-12-12(Н130)ZX4 SH12X1020RNLDCW | Hose | |
| 24 | 87312-12-12Z/87392-12-12ZX4SH12X9 00RNLDCW | Hose | |
| 25 | FL-12Z | Flange | |
| 26 | 87312-16-12Z/87392-12-12ZX4SH12X1 300DCW | Hose | |
| 27 | 87312-16-12Z/20592-36-12TZX4SH12X 1270 | Hose | |
| 28 | GB/T 5783-2000 | Bolt | |
| 29 | GB/T 93-1987 | Washer | |
| 30 | GB/T 97.2-2002 | Washer | |
| 31 | Z38G1008T1 | Tilting Cylinder Assembly | |
| 32 | Z38G1006T1 | Assembly Tilting Cylinder | |
| 33 | Z38G1007T1 20491-16-04Z/20411-16-04ZX1T04ITX | Assembly | |
| 34 | 1800 20441-16-04Z/20411-16-04ZX1T04ITX | Hose | |
| 35 | 1100 | Hose | |
| 36 | 6C-16LNZ | Connector | |
| 37 | GB/T 5783-2000 | Bolt | |
| 38 | GB/T 5783-2000 | Bolt | |
| 39 | 20512-36-16ZX4SH16X850 | Hose | |
| 40 | 20512-36-16Z/20592-36-16ZX4SH16X8 70 | Hose | |
| 41 | Z38G1005T2 | Pilot Hydraulic System | |
| 42 | 20411-30-12ZX1T12X650 | Hose | |
| 43 | 1CH-30-33FAZ | Connector | |
| 44 | 20030-30-12FA | Hose | |
| 45 | 20491-16-04Z/20411-16-04ZX1T04X10 20 | Hose | |
| 46 | Z38G100000003T1 | L Plate | |
| 47 | GB/T 5783-2000 | Bolt | |
| 48 | GB/T 93-1987 | Washer | |
| 49 | Z38G1009T1 | Steel Tube Assembly | |
| 50 | Z38G1010T1 | Steel Tube Assembly | |
| 51 | Z38G1011T1 | Steel Tube Assembly | |
| 52 | Z38G1012T1 | Steel Tube Assembly | |
| 53 | Z38G1013T1 | Multi-way valve T Meatus Assembly | |
| 54 | 2C9-30Z | Connector | |
| 55 | 1DFL9-42-20Z | Connector | |
| 56 | FL-24Z | Flange | |
| 57 | GB/T 5783-2000 | Bolt | |
| 58 | GB/T 5783-2000 | Bolt | |
| 59 | Z38G100000004T1 | Tube Clip | |
| 60 | Z38G100000005T1 | Plate | |
| 61 | GB/T 6170-2000 | Nut | |
| 62 | GB/T 5783-2000 | Bolt | |
| 63 | GB/T 93-1987 | Washer | |
| 64 | K0608-32Z | R clip | |
| 65 | K0608-12Z | R clip | |
| 66 | K0608-35Z | R clip | |
| 67 | GB/T 97.2-2002 | Washer | |
| 68 | Z38G1006T2 | Assembly | |
| 69 | 20592-36-16ZX4SPX830V0 20512-36-16Z/20592-36-16ZX4SP16X7 | Hose | |
| 70 | 80 87692-16-12Z/20491-30-12ZX1T12X55 | Hose | |
| 71 | 81 87692-16-12Z/20491-30-12ZX1T12X55 | Hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
