Каталог запасных частей к технике: ChengGong CG-938H. Frame Group(II)
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
18
19
19
20
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
B1
B1
B1
B1
B2
B2
B2
B2
B2
B2
B2
ВЗ
ВЗ
ВЗ
ВЗ
ВЗ
ВЗ
ВЗ
В4
В4
В4
В4
В4
В5
В5
В5
В5
В5
В5
В5
В5
В5
В5
В5
В6
В6
В6
В6
В6
В7
В8
В8
В8
В8
В8
В8
В9
В10
В11
В12
В13
В14
В15
В15
В15
В16
В16
В16
В17
В17
В17
В18
В18
В18
В19
В19
В19
В20
В20
В20
В21
В21
В22
В22
В23
В23
В24
В24
В25
В26
В26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z38G120401T1 | Left Rear Fender | |
| 2 | Z50G121102T15 | Ladder Of Ballast | |
| 3 | Z38G121103T2 | Door Of Left Boх | |
| 4 | GMS506 | Lock | |
| 5 | Z38G121101T2 | Ballast | |
| 6 | Z38G120402T1 | Brace Of Left Rear Fender | |
| 7 | Z38G120000009T1 | Pin | |
| 8 | Z38G121100005T1 | Fiхing Plate Of Rubber Strip | |
| 9 | Z38G121100007T1 | Rubber Strip | |
| 10 | Z50E120000002T15 | Rubber Plug | |
| 11 | YN20T01282P1 | Skidproof Cushion | |
| 12 | Z38G120000002T2 | Rubber Cushion | |
| 13 | Z38G121100001T2 | Right Close Plate | |
| 14 | Z38G120502T1 | Brace Of Right Rear Fender | |
| 15 | Z38G120501T1 | Right Rear Fender | |
| 16 | Z38G1215T1 | Back Decorative Plate | |
| 17 | Z38G1221T1 | Right Middle Decorative Plate | |
| 18 | Z38G121901T2 | Right Staircase | |
| 19 | Z50G121800001T15 | Rubber Sheath | |
| 20 | Z301211 | Ladder | |
| 21 | Z38G1220T1 | Right Front Decorative Plate | |
| 22 | Z38G121600002T1 | Rubber Strip | |
| 23 | MS606-1-2 | Lock | |
| 24 | Z50G120900004T15 | Shock Absorber | |
| 25 | Z38G121602T2 | Door Of Right Installation Boх | |
| 26 | Z50G121600002T17 | Plate Of underprop | |
| 27 | Z38G1213T1 | Left Front Decorative Plate | |
| 28 | Z38G121702T2 | Door Of Left Installation Boх | |
| 29 | Z38G121801T2 | Left Staircase | |
| 30 | Z50G121101T15 | Ladder Of Ballast | |
| 31 | Z38G1214T1 | Left Middle Decorative Plate | |
| 32 | Z50G120000002T17 | Bolt Of Ballast | |
| 33 | Z38G121102T2 | Door Of Right Boх | |
| 34 | Z38G121601T2 | Right Installation Boх | |
| 35 | Z38G121701T2 | Left Installation Boх | |
| B1 | GB/T5783-2000 | Connector | |
| B2 | GB/T93-87 | Washer 20 | |
| ВЗ | GB/T97.1-2002 | Washer 10 | |
| В4 | GB/T5783-2000 | Connector | |
| В5 | GB/T93-87 | Washer 20 | |
| В6 | GB/T97.1-2002 | Washer 10 | |
| В7 | GB/T5783-2000 | Connector | |
| В8 | GB/T96.1-2002 | Washer 10 | |
| В9 | GB/T6170-2000 | Nut M14 | |
| В10 | GB/T93-87 | Washer 20 | |
| В11 | GB/T97.1-2002 | Washer 10 | |
| В12 | GB/T5783-2000 | Connector | |
| В13 | GB/T819.2 | Bolt M5х16 | |
| В14 | GB/T5783-2000 | Connector | |
| В15 | GB/T93-87 | Washer 20 | |
| В16 | GB/T97.1-2002 | Washer 10 | |
| В17 | GB/T5783-2000 | Connector | |
| В18 | GB/T5783-2000 | Connector | |
| В19 | GB/T93-87 | Washer 20 | |
| В20 | GB/T97.1-2002 | Washer 10 | |
| В21 | GB/T6170-2000 | Nut M14 | |
| В22 | GB/T5783-2000 | Connector | |
| В23 | GB/T5783-2000 | Connector | |
| В24 | GB/T93-87 | Washer 20 | |
| В25 | GB/T6170-2000 | Nut M14 | |
| В26 | GB/T5783-2000 | Connector |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
