Каталог запасных частей к технике: ChengGong CG-935H. Z35H10T13 Work hydraulics System
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z35H1001T13 | Hydraulic oil box | |
| 2 | Z35F1001L | Suck Tube Assembly | |
| 3 | Z35H1002T13 | Pump Suck Tube Assembly | |
| 4 | Z35F100000004A | Suck tube | |
| 5 | 20441-36-16/20411-36-16X1T16GTX400 | Hose assem | |
| 6 | 1CFL9-36-16W | Flange | |
| 7 | 1CFL9-18-08W | Flange | |
| 8 | P5100-F40TF48614/P124-GY18G | Unit pump | |
| 9 | Z35H1006T1320592-36-12Т/20592-36-12Н130 | Flange | |
| 10 | TX4SM12GJX580V270 | Hose assem | |
| 11 | Z35F1015L | Value assem | |
| 12 | 87391-20-16Т/20591-42-16TX3M16GJX2250V0 | Hose assem | |
| 13 | Z35H1003T13 | Value assem | |
| 14 | Z40F1005T13 | Cylinder pipe | |
| 15 | Z40F1004T13 | Cylinder pipe | |
| 16 | 20512-36-12Т/20592-36-12TX4SM12GJX1170 | Hose assem | |
| 17 | 20512-36-12TX4SM12GJX1120 | Hose assem | |
| 18 | Z35F1006L87392-12-12/87342-12-1 | Cylinder assem | |
| 19 | 2X4SP12TKX1250V270+RM | Hose assem | |
| 20 | 87392-12-12Н130/87342-12-12X4SP12TKX1250V270+RM | Hose assem | |
| 21 | 87392-12-12/87342-12-12X4SP12TKX1250V90+RM | Hose assem | |
| 22 | 87392-12-12Н130/87342-12-12X4SP12TKX1250V90+RM | Hose assem | |
| 23 | Z35F1005A | Cylinder assem | |
| 24 | Z35F1009A | Cylinder assem | |
| 25 | Z35H1006 | Clips assem | |
| 26 | 20411-45-20Т/87391-24-20TX1M20GTX1365 | Cylinder assem | |
| 27 | FL-24 | Flange | |
| 28 | Z35H1005 | Clips | |
| 29 | 6С-45 | Connector | |
| 30 | 20411-45-20TX1M20GТХ1050 | Cylinder assem | |
| 31 | Z50F1015A | Clip | |
| 32 | Z35C1007 | Clip assem | |
| 33 | Z35H1004T13 | Value assem | |
| 34 | Z5EH1004T4 | Manul-set box | |
| 35 | Z35H1005T13 | Pipe assem | |
| 36 | 20411-30-12/20491-30-12X1T12GTX1700 | Cylinder assem | |
| 37 | LH-ZL35F | Radiator | |
| 38 | 2С9-30 | Bowl | |
| 39 | GB93-87 | Washer 8 | |
| 40 | GB5783-86 | Bolt M8x20 | |
| 41 | GB5783-86 | Bolt M8x20 | |
| 42 | GB93-87 | Washer 8 | |
| 43 | Z35C100000001 | Paper cushion | |
| 44 | Z50E100000001 | Clamp | |
| 45 | GB93-87 | Washer 8 | |
| 46 | GB5783-86 | Bolt M8x20 | |
| 47 | GB6170-86 | Nut M6 | |
| 48 | GB5783-86 | Bolt M8x20 | |
| 49 | GB6170-86 | Nut M6 | |
| 50 | 1CH-22-33 | Connector | |
| 51 | 20411-22-08X1T08GTX1200 | Hose | |
| 52 | 4C-22 | Plug | |
| 53 | FL-20 | Flange |
