Каталог запасных частей к технике: ChengGong CG-932H. Z33E13T48 Cab
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
18
18
19
19
19
20
21
21
21
22
22
22
23
24
24
25
25
26
27
28
29
30
31
31
32
32
33
34
35
36
37
38
39
40
41
42
43
43
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z33E130101T48 | Cab Body | |
| 2 | CGZY-4 | Seat | |
| 3 | Z5E21307T31 | Instrument Assembly | |
| 4 | Z33E1304 | Steering Wheel | |
| 5 | Z33E1305T9 | Box | |
| 6 | Z33E130000010T48 | Adorning | |
| 7 | Z33E130000001T48 | Floor Board Cushion | |
| 8 | Z33E130000005T48 | Glass | |
| 9 | Z33E130000006T48 | Glass | |
| 10 | Z5E3130000006T16 | Glass | |
| 11 | Z33E130000007T48 | Glass | |
| 12 | JDLB-001 | Bracket | |
| 13 | Z5E2130000011T8 | Boarding | |
| 14 | Z5E2130000012T8 | Boarding | |
| 15 | Z5E2130000013T8 | Rubber | |
| 16 | Z30B130000010T37 | Boarding | |
| 17 | GB/T5783-2000 | Connector | |
| 18 | GB/T93-1987 | Valve | |
| 19 | GB/T97.1-2002 | Washer 10 | |
| 20 | GB/T5783-2000 | Connector | |
| 21 | GB/T93-1987 | Valve | |
| 22 | GB/T97.1-2002 | Washer 10 | |
| 23 | GB/T818-2000 | Bolt M4x20 | |
| 24 | GB/T93-1987 | Valve | |
| 25 | GB/T97.1-2002 | Washer 10 | |
| 26 | Z50G130000026T15 | Sheet | |
| 27 | GB/T846-1985 | Bolt ST4.2x16 | |
| 28 | Z5E2130000004T11 | Rubber | |
| 29 | Z5E2130000003T11 | Rubber | |
| 30 | SE9050-25-1160 | Absorber | |
| 31 | Z5E2130000010T31 | Sheet | |
| 32 | GB/T5785-2000 | Bolt | |
| 33 | SE9050-25-1155 | Absorber | |
| 34 | Z5E31302T16 | Window | |
| 35 | CG-B80A-1 | Bracket | |
| 36 | DJC-WZ-11160 | Pipe Assembly | |
| 37 | S9695 | Clip | |
| 38 | Z33E1309T9 | Bracket | |
| 39 | GB/T5783-2000 | Connector | |
| 40 | GB/T5783-2000 | Connector | |
| 41 | GB/T5783-2000 | Connector | |
| 42 | GB/T818-2000 | Bolt M4x20 | |
| 43 | GB/T6170-2000 | Nut M14 | |
| 44 | Z5E3121700002T16 | Rubber Ф 50-70X5 |
