Каталог запасных частей к технике: ChengGong CG-932H. Z33E12T35 Frame Group
1
2
3
4
4
4
4
4
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
16
16
17
18
19
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z33E120503T34 | Right Rear Fender | |
| 2 | YN20T01282P1 | Skidproof Cushion | |
| 3 | GB/T5783-2000 | Connector | |
| 4 | GB/T93-1987 | Valve | |
| 5 | GB/T6170-2000 | Nut M14 | |
| 6 | Z33E120403003 | Foot Treadle | |
| 7 | Z33E120502T9 | Back Support | |
| 8 | Z33E120400001T7 | Foot Treadle | |
| 9 | Z33E120501T9 | Front Support | |
| 10 | GB/T5783-2000 | Connector | |
| 11 | GB/T93-1987 | Valve | |
| 12 | GB/T97.1-2002 | Washer 10 | |
| 13 | Z33E120401T7 | Front Support | |
| 14 | Z33E120402T7 | Back Support | |
| 15 | GB/T5782-2000 | Bolt | |
| 16 | GB/T97.1-2002 | Washer 10 | |
| 17 | GB/T5782-2000 | Bolt | |
| 18 | Z33E120403001 | Plate | |
| 19 | Z38G121800002T3 | Adhesive Of Foot Treaddle | |
| 20 | Z33E120403002 | Plate | |
| 21 | GB/T5783-2000 | Connector | |
| 22 | GB/T93-1987 | Valve | |
| 23 | GB/T97.1-2002 | Washer 10 | |
| 24 | GB/T5783-2000 | Connector | |
| 25 | Z33E120404T34 | Left Rear Fender | |
| 26 | GB/T5783-2000 | Connector | |
| 27 | GB/T5783-2000 | Connector | |
| 28 | GB/T93-1987 | Valve | |
| 29 | GB/T97.1-2002 | Washer 10 | |
| 30 | Z55S120400001T11 | Fender Bracket | |
| 31 | GB/T5783-2000 | Connector | |
| 32 | GB/T93-1987 | Valve | |
| 33 | Z33E120000019T35 | Washer | |
| 34 | Z33E120000001T35 | Shim | |
| 35 | Z33E120000002T35 | Shim | |
| 36 | Z33E120000003T35 | Shim | |
| 37 | Z33E120000004T35 | Shim | |
| 38 | Z33E120000005T35 | Shim | |
| 39 | Z5E3121600002T16 | Rubber Band 50x5 | |
| 40 | Z33E121106T42 | Plate | |
| 41 | Z33E121102T42 | Plate | |
| 42 | GB/T5783-2000 | Connector | |
| 43 | GB/T96.1-2002 | Washer 10 | |
| 44 | GB/T5782-2000 | Bolt | |
| 45 | GB/T93-1987 | Valve | |
| 46 | GB/T97.1-2002 | Washer 10 | |
| 47 | GB/T5783-2000 | Connector | |
| 48 | Z33E120000015 | Press Plate | |
| 49 | Z33E120000016 | Eraser | |
| 50 | GB/T5783-2000 | Connector | |
| 51 | GB/T93-1987 | Valve | |
| 52 | GB/T5783-2000 | Connector | |
| 53 | GB/T96.1-2002 | Washer 10 | |
| 54 | GB/T93-1987 | Valve | |
| 55 | Z33E121103T42 | Plate | |
| 56 | Z33E121100001T42 | Plate | |
| 57 | GMS509 | Lock | |
| 58 | GB/T5783-2000 | Connector | |
| 59 | GB/T96.1-2002 | Washer 10 | |
| 60 | Z50G130000023T15 | Glue | |
| 61 | GB/T5783-2000 | Connector | |
| 62 | Z5E2121105T45 | Foot Treadle | |
| 63 | Z33E121101T34 | Ballast |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
