Каталог запасных частей к технике: ChengGong CG-932H. Z33E03T34 Transmission
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
87
88
88
88
88
89
90
91
92
93
94
94
95
96
97
98
98
99
100
101
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
133
134
134
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z33E0301T7 | Combining Gear Set | |
| 2 | Z3BII0302 | DrivingDisk-1st Reverse | |
| 3 | Z3BII0303 | Reverse-Range Plate | |
| 4 | Z3BII0304 | Friction Disks Assmebly | |
| 5 | Z3BII0305 | 1st-Range Plate | |
| 6 | Z3BII0306 | 1st-Range Gear Assembly 2st-Range | |
| 7 | Z3BII0307 | Cylinder Assembly | |
| 8 | Z3BII0308 | Driving Disk-2nd Forward | |
| 9 | Z33E0303 | Handle-brake Assembly | |
| 10 | Z33E0304T23 | Flange Subassembly | |
| 11 | Z3BII0311 | Driving Gear-2nd Forward | |
| 12 | Z30B0305T38 | Bracket | |
| 13 | Z33E0302T23 | Suction Line Assembly | |
| 14 | YLX-558-J | Filter | |
| 15 | Z33E0303T23 | Filler Pipe Assembly | |
| 16 | Z3BII030000001 | O-Ring Seal | |
| 17 | Z3BII030000002 | Sun Gear | |
| 18 | Z3BII030000003 | Adjusting Shim | |
| 19 | Z3BII030000004 | Internal Seal Ring | |
| 20 | Z3BII030000005 | Piston-Reverse | |
| 21 | Z3BII030000006 | External Seal Ring Return Spring 1st Reverst | |
| 22 | Z3BII030000007 | Piston | |
| 23 | Z3BII030000008 | Spring Guide Rod | |
| 24 | Z3BII030000009 | Driven Plate-1st Reverse | |
| 25 | Z3BII030000010 | Spacer | |
| 26 | Z33E030000001T23 | Transmission Housing | |
| 27 | Z3BII030000012 | Piston-1st Forward | |
| 28 | Z3BII030000013 | Internal Seal Ring | |
| 29 | Z3BII030000014 | Cylinder-1st Forward | |
| 30 | Z3BII030000001T37 | Gear | |
| 31 | Z3BII030000016 | Ring Gear -1st Forward | |
| 32 | Z3BII030000017 | Piston-1st Forward | |
| 33 | Z3BII030000018 | External Seal Ring | |
| 34 | Z3BII030000019 | Piston-2nd Forward | |
| 35 | Z3BII030000020 | Right Cover | |
| 36 | Z3BII030000021 | Tighten Iron | |
| 37 | Z3BII030000022 | Oil Sleeve | |
| 38 | Z3BII030000023 | Shaft Cover | |
| 39 | Z3BII030000024 | Input Shaft -Rear | |
| 40 | Z3BII030000025 | Internal Seal Ring | |
| 41 | Z3BII030000026 | Thread Plug | |
| 42 | Z3BII030000027 | Driven Plate-2nd Foiwd | |
| 43 | GB/T1235-1976 | O-Ring Seal 22X24 | |
| 44 | Z3BII030000029 | Right Cover | |
| 45 | Z33E030000003T23 | Flange | |
| 46 | Z3BII030000031 | Output Shaft-Front | |
| 47 | Z33E030000002 | Brake Plate | |
| 48 | Z3BII030000033 | Adjusting Shim | |
| 49 | Z3BII030000034 | Spacer | |
| 50 | Z3BII030000002T37 | Driven Gear | |
| 51 | GB/T6170-2000 | Nut M14 | |
| 52 | Z3BII030000037 | Sleeve | |
| 53 | Z3BII030000038а | Plate | |
| 54 | GB/T97. 1-2002 | Washer 16 | |
| 55 | Z3BII030000040а | Magnet | |
| 56 | Z3BII030000041 | Bushing | |
| 57 | Z3BII030000042 | Sliding Sleeve | |
| 58 | Z3BII030000043 | Locating Spring | |
| 59 | Z3BII030000044 | Output Shaft Rear | |
| 60 | Z3BII030000045 | Paper Gasket | |
| 61 | Z3BII030000046 | Left Cover | |
| 62 | GB/T1235-1976 | O-Ring Seal 85X5.7 | |
| 63 | Z3BII030000048 | Spacer | |
| 64 | Z33E030000004 | Dust Shroud | |
| 65 | Z30B030000010T38 | Board | |
| 66 | 20Y-36R-00 | shock absorber | |
| 67 | Z3BII030000052 | Clamping Ring | |
| 68 | Z33E030000003 | Adjusting Shim | |
| 69 | Q/CG302.11-2002 | Washer | |
| 70 | GB/T898-1988 | Bolt | |
| 71 | GB/T5783-2000 | Connector | |
| 72 | Z3BII030000057 | Set Screw | |
| 73 | Z3BII030000058 | Pin End Cover | |
| 74 | Z3BII030000059 | Plunger | |
| 75 | GB/T6171-2000 | Nut 18 | |
| 76 | Z3BII030000061 | Shift Fork | |
| 77 | Z3BII030000062 | Shaft-Shift Fork | |
| 78 | Z3BII030000063 | Lining-Oil Sea | |
| 79 | Z3BII030000064 | Input Shaft Front | |
| 80 | Z3BII030000065 | Key | |
| 81 | В80А020000005 | Adjusting Shim | |
| 82 | Z3BII030000067 | O-RingSeal | |
| 83 | 4HN-22 | Thread Plug | |
| 84 | DTF-CO | Nut | |
| 85 | Z30B030000007T38 | Plate | |
| 86 | Z3BII030000070 | Seal Gasket | |
| 87 | GB/T5783-2000 | Connector | |
| 88 | GB/T93-1987 | Valve | |
| 89 | GB/T32. Ы988 | Bolt M10X65 | |
| 90 | GB/T97. 1-2002 | Washer 16 | |
| 91 | GB/T276-1994 | Bearing | |
| 92 | GB/T894.1-1986 | Snap Ring | |
| 93 | GB/T5783-2000 | Connector | |
| 94 | GB/T93-1987 | Valve | |
| 95 | GB/T276-1994 | Bearing | |
| 96 | GB/T5783-2000 | Connector | |
| 97 | GB/T5783-2000 | Connector | |
| 98 | GB/T93-1987 | Valve | |
| 99 | GB/T13871-1992 | Oil Seal | |
| 100 | GB/T5783-2000 | Connector | |
| 101 | GB/T93-1987 | Valve | |
| 102 | GB/T276-1994 | Bearing | |
| 103 | GB/T276-1994 | Bearing | |
| 104 | Z3BII030000039 | Snap Ring | |
| 105 | GB/T5783-2000 | Connector | |
| 106 | GB/T93-1987 | Valve | |
| 107 | GB/T308-2002 | Ball 10 | |
| 108 | GB/T893. Ы986 | Snap Ring 150 | |
| 109 | GB/T93-1987 | Valve | |
| 110 | GB/T6170-2000 | Nut M14 | |
| 111 | GB/T276-1994 | Bearing | |
| 112 | Z2BII030000075 | Nut M27X1.5 | |
| 113 | GB/T91-2000 | Pin 4.5х45 | |
| 114 | GB/T97.1-2002 | Washer 10 | |
| 115 | GB/T13871-1992 | Oil Seal | |
| 116 | GB/T893. 1-1986 | Snap Ring | |
| 117 | GB/T5783-2000 | Connector | |
| 118 | GB/T5785-2000 | Bolt | |
| 119 | GB/T1235-1976 | O-Ring Seal 22X24 | |
| 120 | GB/T95-2002 | Washer 12 | |
| 121 | GB/T901-1988 | Stud BM8X35 | |
| 122 | GB/T893. 1-1986 | Snap Ring | |
| 123 | GB/T5782-2000 | Bolt | |
| 124 | GB/T97.1-2002 | Washer 10 | |
| 125 | GB/T5783-2000 | Connector | |
| 126 | 1CH-22 | Connector | |
| 127 | Z3BII030000071 | Adjusting Shim | |
| 128 | Z3BII030000072 | Adjusting Shim | |
| 129 | B80A020000008 | Adjusting Shim | |
| 130 | В80А020000009 | Adjusting Shim | |
| 131 | Z33E030000005 | Adjusting Shim | |
| 132 | Z33E030000006 | Adjusting Shim | |
| 133 | Z3BII030000073 | Spacer | |
| 134 | Z3BII030000074 | Spacer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
