Каталог запасных частей к технике: ChengGong CG-932H. Z33E0301T7 Combining Gear Set
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
34
35
36
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z33E030101T7 | Powe Shift Pump | |
| 2 | Z3BII030102 | Exceed Clutch | |
| 3 | GB/T898-1988 | Bolt | |
| 4 | Z3BII030100026 | Union | |
| 5 | Z3BII030104 | Breather | |
| 6 | Z3BII030100001 | 2nd Input Gear | |
| 7 | Z3BII030100002 | 1st Input Gear | |
| 8 | Z3BII030100003 | Oil Seal Ring-2nd Gear | |
| 9 | Z3BII030100004 | Oil Seal Ring-1st Gear | |
| 10 | Z3BII030100005 | Bushing | |
| 11 | Z3BII030100006 | Spacer | |
| 12 | Z3BII030100007 | Copper Pipe | |
| 13 | ZL30B.3.1-8А | Housing | |
| 14 | Z3BII030100009 | Gasket | |
| 15 | Z3BII030100010 | Shaft-Oil Pump | |
| 16 | Z3BII030100011 | Spacer | |
| 17 | Z3BII030100012 | Valve Cover | |
| 18 | Z3BII030100013 | Adjusting Screw | |
| 19 | Z3BII030100014 | Nut | |
| 20 | Z3BII030100015 | Gasket | |
| 21 | Z3BII030100016 | Spring | |
| 22 | Z3BII030100020 | Gasket | |
| 23 | Z3BII030100018 | Clip | |
| 24 | Z3BII030100019 | Valve | |
| 25 | GB/T5782-2000 | Bolt | |
| 26 | Z3BII030100021 | Shaft-Steering Pump | |
| 27 | Z33E030100002T7 | Flange-Steering Pump | |
| 28 | 1CH-30-27Z | Connector | |
| 29 | Z3BII030100024 | Gear | |
| 30 | Z3BII030100025 | Spacer | |
| 31 | GB/T3452. 1-2005 | O-Ring Seal 103X3.55 | |
| 32 | GB/T3452. 1-2005 | O-Ring Seal 92.5X3.55 | |
| 33 | GB/T5783-2000 | Connector | |
| 34 | GB/T93-1987 | Valve | |
| 35 | GB/T276-1994 | Bearing | |
| 36 | GB/T276-1994 | Bearing | |
| 37 | GB/T276-1994 | Bearing | |
| 38 | GB/T301-1995 | Bearing 51111 | |
| 39 | GB/T276-1994 | Bearing | |
| 40 | GB/T6170-2000 | Nut M14 | |
| 41 | GB/T93-1987 | Valve | |
| 42 | ZL50.3-38 | Adjusting Shim | |
| 43 | GB/T276-1994 | Bearing | |
| 44 | GB/T276-1994 | Bearing | |
| 45 | GB/T893.1-1986 | Snap Ring | |
| 46 | GB/T276-1994 | Bearing | |
| 47 | GB/T70. 1-2000 | Bolt M12X30 | |
| 48 | GB/T276-1994 | Bearing | |
| 49 | GB/T5783-2000 | Connector | |
| 50 | GB/T93-1987 | Valve | |
| 51 | GB/T13871-1992 | Oil Seal | |
| 52 | GB/T13871-1992 | Oil Seal | |
| 53 | ZL50.3-39 | Adjusting Shim | |
| 54 | ZL50.3-40 | Adjusting Shim | |
| 55 | Z33E030100003T7 | Protective Sheet |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
