Каталог запасных частей к технике: ChengGong CG-932H. Z33E10T7 Working Hydraulic System

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

16

16

17

18

19

20

21

22

23

24

24

24

25

26

27

27

28

30

31

31

31

31

32

32

32

33

33

34

35

36

37

38

39

40

41

42

43

44

Позиция на иллюстрации	Заводской номер детали		Название детали
1	Z33E1001T7		Hydraulic Oil Tank
2	Z33E1002T7		Oil Tube Assembly
3	Z33E1003T7		Multi-Way Valve Asse
4	Z33E1004T7		Left Lift Cylin. Asse
5	Z33E1005T7		Tilt Cylinder Asse
6	Z33E1006T7		Steel Tube Assembly
7	Z33E1007T7		Steel Tube Assembly
8	Z33E1008T7		Cylinder Assembly
9	Z33E1009		Oil Tube Assembly
10	Z33E1010		Bracket.
11	Z33E1011T7		Oil system Assembly
12	Z33E1012T7		Board Assembly
13	Z33E1013T7		Nip Assembly
14	JHP2090		Gear Pump
15	Z3BII100000001		Paper Washer
16	FL-20		Flange
17	1DFL9-42-2020592-42-16TZ		Connector
18	4SP391-16X1870V90		Hose
19	0AQTZXGH793-10X1200		Hose
20	0AQTZXGH793-10X1120		Hose
21	0AQTZXGH793-10X1200		Hose
22	0AQTZXGH793-10X1120		Hose
23	SM16GJX1080		Hose
24	87312-20-16Z		Hose
25	FL-12		Connector
26	FL-16		Connector
27	20411-45-20TZ		Hose
28	HCI-32		Nip
29	LJ135BX2L2020-II		Control Mechanism
30	GB/T97.2-2002		Washer 24
31	GB/T93-1987		Valve
32	GB/T5783-2000		Connector
33	GB/T93-1987		Valve
34	GB/T5783-2000		Connector
35	GB/T5783-2000		Connector
36	CG50.10.2.1-2		Connector
37	GB/T91-2000		Pin 4.5х45
38	GB/T882-2000		Pin
39	GB/T95-2002		Washer 12
40	GB/T5783-2000		Connector
41	HCI-28		Nip
42	1CH-22-33		Connector
43	20411-22-08X1T08GTX1200		Hose
44	4C-22		Plug

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
